0118 22 27 39 by Parker | Legris Stud Fitting w/ Bi-Material Seal | 22 mm Tube Size x 3/4" Male BSPP Thread | 36 mm Hex | Banjo | Brass | Pack of 5

Save $38.28

$421.08

$421.08 - $421.08

$421.08

$382.80

$382.80 - $382.80

$382.80

by Parker Hannifin
Brass Compression Fittings / Stud Fittings:0118..39 Single Banjo with Bi-Material Seal, Male BSPP Thread

Package Quantity: 5 Units

Quantity

Specifications for Variant SKU: 0118 22 27 39 Parker \| 5 \|
Series:	0118 39 Series
Shape (Orientation):	Banjo
Material(s):	Brass, Zinc-Plated Steel
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Fuel Grade

Technical Characteristics:	Compatible Fluids: Water, machining oil, fuel, hydraulic oil, compressed air, chemical fluids, disinfectants Working Pressure: Vacuum to 550 bar Working Temperature: -60°C to +250°C (without sealing washer, with metal tubing)
Advantages:	22 configurations Excellent sealing due to the tightening of the olive onto the tube Metallic sealing for optimum service life, pressure, and temperature ranges Connection of different types of tubing and hose: metal, polymer, steel, rubber, etc. Multiple tube diameters can be connected using the Legris reducer assembly system
Regulations:	RoHS PED REACH
Component Materials:


Part Number	ØD	C	F	F1	H	H1	L (max)	L1	N	Kg
0118 04 10 39	4 mm	1/8"	14 mm	10 mm	23 mm	9.5 mm	24 mm	14.5 mm	17.5 mm	.040 Kg
0118 05 10 39	5 mm	1/8"	14 mm	12 mm	23 mm	9.5 mm	25 mm	14.5 mm	17.5 mm	.042 Kg
0118 06 10 39	6 mm	1/8"	14 mm	13 mm	23 mm	9.5 mm	25 mm	14.5 mm	17.5 mm	.043 Kg
0118 06 13 39	6 mm	1/4"	17 mm	13 mm	24 mm	10 mm	26 mm	16 mm	21 mm	.058 Kg
0118 08 10 39	8 mm	1/8"	14 mm	14 mm	23 mm	9.5 mm	28 mm	15.5 mm	17.5 mm	.055 Kg
0118 08 13 39	8 mm	1/4"	17 mm	14 mm	24 mm	10 mm	28 mm	28 mm	15.5 mm	.21 Kg
0118 10 13 39	10 mm	1/8"	14 mm	10 mm	23 mm	9 mm	24 mm	14 mm	17 mm	.040 Kg
0118 10 17 39	10 mm	3/8"	22 mm	19 mm	31.5 mm	13.5 mm	34 mm	19 mm	26.5 mm	.128 Kg
0118 12 17 39	12 mm	3/8"	22 mm	22 mm	34.5 mm	15 mm	34 mm	19 mm	26.5 mm	.0137 Kg
0118 14 17 39	14 mm	3/8"	22 mm	24 mm	37.5 mm	16.5 mm	37 mm	20.5 mm	28 mm	.196 Kg
0118 14 21 39	14 mm	1/2"	27 mm	24 mm	39 mm	16.5 mm	38 mm	20.5 mm	32.5 mm	.207 Kg
0118 15 21 39	15 mm	1/2"	27 mm	27 mm	40 mm	16.5 mm	38 mm	20.5 mm	32.5 mm	.202 Kg
0118 22 27 39	22 mm	3/4"	32 mm	36 mm	54 mm	22.5 mm	45 mm	24.5 mm	39 mm	.467 Kg

With bi-material sealing washer
The bi-material sealing washers, part number 0139, can be found in the sub-chapter “Adaptors and Manifolds”.
