0171 02 10 01 by Parker | Legris Coupler Quick Disconnect | 2mm Diameter Nominal x 1/8" Male BSPT Thread | 10 mm Hex | Black | Straight | Nickel-Plated Brass | Pack of 10

Save $34.36 Save $34.36
Original price $377.93
Original price $377.93 - Original price $377.93
Original price $377.93
Current price $343.57
$343.57 - $343.57
Current price $343.57

by Parker Hannifin
Metal Quick-Acting Couplers:0171 Coupler with valve, Male BSPT and Parallel Metric Thread

Unit Price: $34.36 per EA

Package Quantity: 10 EA

 More payment options
Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

NaN
Specifications for Variant SKU: 0171 02 10 01 Parker | 10 |
Series: 0171 Series
Shape (Orientation): Straight
Special Properties: Ergonomic
Mini Series: The mini series offer space saving solutions for frequent disconnection of tubing or pneumatic tools.
  • Compact and ergonomic
  • Easy identification of circuits
  • Easy disconnection / single hand operation
Working Pressure:
  • up to 20 bar
Material:
  • Coupling: Technical Polymer, Nickel-Plated Brass
  • Plug: Nickel-Plated Brass
  • Seals: NBR
Working Temperature:
  • -20°C up to +60°C (NBR)
Flow Rate Air:
  • 165 Nl/min. (inlet pressure 6 bar, pressure dop 0.6 bar)
Part Number Diameter Nominal (DN) C F G L Kg
0171 02 10 01 2 1/8" 7.5 mm 10 mm 21 mm ..01 Kg
0171 02 10 04 2 1/8" 7.5 mm 10 mm 21 mm ..01 Kg

Single shut-off
Mini Series (DN 2): single shut-off= 165 Nl/min
