1/2" DH16 Couplamatic DURA-HYD Abrasion Resistant Extra Hi-Pressure Hydraulic Hose (SAE 100R16/2SC) - 1/2" ID - 300ft

1/2" DH16 by Couplamatic | DURA-HYD Abrasion Resistant | Extra Hi-Pressure Hydraulic Hose | SAE 100R16/2SC | 1/2" ID | 300ft

Save $94.00

$846.00

$846.00 - $846.00

$846.00

$752.00

$752.00 - $752.00

$752.00

Couplamatic Systems Inc.
Two Wire Braid Hoses - DH16 DURA-HYD Abrasion Resistant Extra Hi-Pressure Hydraulic Hose -(SAE 100R16/2SC)

Package Quantity: 300 FT

Quantity

Specifications for Variant SKU: 1/2" DH16 Couplamatic \| 300 \|
Series:	DH16 Series
Hose Color(s):	Black
Dash Size:	-8
Internal Diameter:	0.50in
Outer Diameter:	0.812in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R16
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series

Applications:	High Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R16/2SC
Cover:	Flame Resistant, Extra Abrasion Resistant, MSHA approved.	Reinforcement:	Two Wire Braids
Temperature:	-40F to +212F (-40C to +100C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" DH16	1/4"	0.530"	5,800 lbs.	23,200 lbs.	2"	18 lbs.	500ft
3/8" DH16	3/8"	0.687"	5,000 lbs.	20,000 lbs.	2.5"	27 lbs.	400ft
1/2" DH16	1/2"	0.812"	4,250 lbs.	17,000 lbs.	3.5"	35 lbs.	300ft
5/8" DH16	5/8"	0.937"	3,625 lbs.	14,500 lbs.	4"	40 lbs.	250ft
3/4" DH16	3/4"	1.090"	3,125 lbs.	12,500 lbs.	4.8"	54 lbs.	250ft
1" DH16	1"	1.405"	2,500 lbs.	10,000 lbs.	6"	74 lbs.	200ft
