1/2" H7TLNC by Couplamatic | Twin Line Non-Conductive | Thermoplastic Hydraulic Hose | Polyester Braid | SAE 100R7 | 1/2" ID | 250ft

Save $194.63 Save $194.63
Original price $1,946.30
Original price $1,946.30 - Original price $1,946.30
Original price $1,946.30
Current price $1,751.67
$1,751.67 - $1,751.67
Current price $1,751.67

Couplamatic Systems Inc.
Polyester Braid - H7TLNC Non-Conductive Twin Line Thermoplastic Hydraulic Hose - (SAE 100R7)

Package Quantity: 250 FT

Specifications for Variant SKU: 1/2" H7TLNC Couplamatic | 250 |
Series: H7TLNC Series
Hose Color(s): Orange
Dash Size: -8
Internal Diameter: 0.50in
Outer Diameter: 0.815in
Tubing Construction: Nylon
Cover Construction: Polyurethane
Applicable Specs & Approvals: SAE 100R7
Compatible with the following Series: 3 Series  |   T Series
Applications: Medium Pressure Hydraulics, Industrial or Agricultural SAE Rating: SAE 100R7
Cover: Orange Non-Conductive Polyurethane, Non-Perforated Tube: Nylon
Reinforcement: Polyester Braid Temperature: -40F to +212F (-40C to +100C)
Part Number Hose ID Hose OD Working Pressure
(lbs)
Min. Burst Pressure
(lbs)
Min. Bend Radius Weight per 100ft Coil Footage
1/4" H7TLNC 1/4" 0.508" 2,750 lbs. 11,000 lbs. 1.5" 12 lbs. 250ft
5/16" H7TLNC 5/16" 0.585" 2,500 lbs. 10,000 lbs. 1.75" 16.6 lbs. 250ft
3/8" H7TLNC 3/8" 0.650" 2,250 lbs. 9,000 lbs. 2" 21 lbs. 250ft
1/2" H7TLNC 1/2" 0.815" 2,000 lbs. 8,000 lbs. 3" 34 lbs. 250ft


Couplamatic Systems Inc

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.

Shop Parts by Couplamatic Systems Inc
