1/2" HS8 Couplamatic Thermoplastic Hydraulic Hose - Aramid Braid (SAE 100R8) - 1/2" ID - 250ft

1/2" HS8 by Couplamatic | Thermoplastic Hydraulic Hose | Aramid Braid | SAE 100R8 | 1/2" ID | 250ft

Save $152.04 Save $152.04
$1,520.37
$1,520.37 - $1,520.37
$1,520.37
$1,368.33
$1,368.33 - $1,368.33
$1,368.33

Couplamatic Systems Inc.
Aramid Braid - HS8 Thermoplastic Hydraulic Hose - (SAE 100R8)

Package Quantity: 250 FT

Specifications for Variant SKU: 1/2" HS8 Couplamatic | 250 |
Series: HS8 Series
Hose Color(s): Black
Dash Size: -8
Internal Diameter: 0.50in
Outer Diameter: 0.815in
Tubing Construction: Nylon
Cover Construction: Polyurethane
Applicable Specs & Approvals: SAE 100R8
Compatible with the following Series: 3 Series
Applications: High Pressure Hydraulics, Industrial or Agricultural SAE Rating: SAE 100R8
Cover: Black Polyurethane, Perforated Tube: Nylon
Reinforcement: Aramid Braid Temperature: -40F to +212F (-40C to +100C)
Part Number Hose ID Hose OD Working Pressure
(lbs)		 Min. Burst Pressure
(lbs)		 Min. Bend Radius Weight per 100ft Coil Footage
3/16" HS8 3/16" 0.433" 5,000 lbs. 20,000 lbs. 1.5" 5 lbs. 250ft
1/4" HS8 1/4" 0.508" 5,000 lbs. 20,000 lbs. 2" 6 lbs. 250ft
3/8" HS8 3/8" 0.650" 4,000 lbs. 16,000 lbs. 2.5" 8 lbs. 250ft
1/2" HS8 1/2" 0.815" 3,500 lbs. 14,000 lbs. 4" 13 lbs. 250ft
Couplamatic Systems Inc

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
