1/2" HS8NC Couplamatic Non-Conductive Thermoplastic Hydraulic Hose - Aramid Braid (SAE 100R8) - 1/2" ID - 250ft

1/2" HS8NC by Couplamatic | Non-Conductive | Thermoplastic Hydraulic Hose | Aramid Braid | SAE 100R8 | 1/2" ID | 250ft

Save $164.07 Save $164.07
$1,640.74
$1,640.74 - $1,640.74
$1,640.74
$1,476.67
$1,476.67 - $1,476.67
$1,476.67

Couplamatic Systems Inc.
Aramid Braid - HS8NC Non-Conductive Thermoplastic Hydraulic Hose - (SAE 100R8)

Package Quantity: 250 FT

Specifications for Variant SKU: 1/2" HS8NC Couplamatic | 250 |
Series: HS8NC Series
Hose Color(s): Orange
Dash Size: -8
Internal Diameter: 0.50in
Outer Diameter: 0.815in
Tubing Construction: Nylon
Cover Construction: Polyurethane
Applicable Specs & Approvals: SAE 100R8
Compatible with the following Series: 4 Series
Applications: High Pressure Hydraulics, Industrial or Agricultural SAE Rating: SAE 100R8
Cover: Orange Non-Conductive Polyurethane, Non-Perforated Tube: Nylon
Reinforcement: Aramid Braid Temperature: -40F to +212F (-40C to +100C)
Part Number Hose ID Hose OD Working Pressure
(lbs)		 Min. Burst Pressure
(lbs)		 Min. Bend Radius Weight per 100ft Coil Footage
1/4" HS8NC 1/4" 0.508" 5,000 lbs. 20,000 lbs. 2" 6 lbs. 250ft
3/8" HS8NC 3/8" 0.650" 4,000 lbs. 16,000 lbs. 2.5" 8 lbs. 250ft
1/2" HS8NC 1/2" 0.815" 3,500 lbs. 14,000 lbs. 4" 13 lbs. 250ft
