1/2" SP580 Couplamatic Four Spiral High Pressure Hydraulic Hose (Caterpillar) - 4 Spirals (SAE 100R12) - 1/2" ID - 50ft

1/2" SP580 by Couplamatic | Four Spiral High Pressure Hydraulic Hose | Caterpillar | 4 Spirals | SAE 100R12 | 1/2" ID | 50ft

Save $33.89

$402.22

$402.22 - $402.22

$402.22

$368.33

$368.33 - $368.33

$368.33

Couplamatic Systems Inc.
4 Spirals - SP580 Four Spiral High Pressure Hydraulic Hose (Caterpillar) - (SAE 100R12)

Package Quantity: 50 FT

Quantity

Specifications for Variant SKU: 1/2" SP580 Couplamatic \| 50 \|
Series:	SP580 Series
Hose Color(s):	Black
Dash Size:	-8
Internal Diameter:	0.50in
Outer Diameter:	0.935in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R12
Compatible with the following Series:	GW Series \| 4GC Series

Applications:	High Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R12
Cover:	Abrasion and Flame Resistant Black Cover, MSHA approved	Reinforcement:	4 Spirals
Temperature:	-40F to +250F (-40C to +121C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
1/2" SP580	1/2"	0.935"	4,000 lbs.	16,000 lbs.	3.5"	50 lbs.	50ft
3/4" SP580	3/4"	1.210"	4,000 lbs.	16,000 lbs.	4.75"	81 lbs.	50ft
1" SP580	1"	1.495"	4,000 lbs.	16,000 lbs.	6"	119 lbs.	50ft
1-1/4" SP580	1-1/4"	1.850"	3,000 lbs.	12,000 lbs.	8.25"	155 lbs.	50ft
1-1/2" SP580	1-1/2"	2.105"	2,500 lbs.	10,000 lbs.	10"	181 lbs.	50ft
2" SP580	2"	2.626"	2,500 lbs.	10,000 lbs.	12.5"	256 lbs.	50ft

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
