1/4" R18 Couplamatic Low Temp Thermoplastic Hydraulic Hose - 3000 PSI - Polyester Braid (SAE 100R18) - 1/4" ID - 250ft

1/4" R18 by Couplamatic | Low Temp | Thermoplastic Hydraulic Hose | 3000 PSI | Polyester Braid | SAE 100R18 | 1/4" ID | 250ft

Save $53.33

$533.33

$533.33 - $533.33

$533.33

$480.00

$480.00 - $480.00

$480.00

Couplamatic Systems Inc.
Polyester Braid - R18 Low Temp Thermoplastic Hydraulic Hose - 3000 PSI - (SAE 100R18)

Package Quantity: 250 FT

Quantity

Specifications for Variant SKU: 1/4" R18 Couplamatic \| 250 \|
Series:	R18 Series
Hose Color(s):	Black
Dash Size:	-4
Internal Diameter:	0.25in
Outer Diameter:	0.47in
Tubing Construction:	Thermoplastic Elastomer
Cover Construction:	Polyester Elastomer
Applicable Specs & Approvals:	SAE 100R18
Compatible with the following Series:	3 Series

Applications:	Medium Pressure Hydraulics, Industrial or Agricultural, Cold Storage and Refrigerated Areas	SAE Rating:	SAE 100R18
Cover:	Black Polyester Elastomer (Non-Stick), Perforated	Tube:	Polyester Elastomer
Reinforcement:	Polyester Braid	Temperature:	-70F to +212F (-57C to +100C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
1/4" R18	1/4"	0.470"	3,000 lbs.	12,000 lbs.	1.25"	6 lbs.	250ft
3/8" R18	3/8"	0.650"	3,000 lbs.	12,000 lbs.	2.00"	10 lbs.	250ft

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
