Name: 1161X6M by Danfoss | Metric Push to Connect Adapter | Cartridge | 6mm Tube OD | Nickel Plated Brass
Brand: Danfoss/Eaton
SKU: 1161X6M Danfoss
Price: 14.49 USD
Availability: InStock

$14.49 - $14.49

$14.49

$14.49 - $14.49

$14.49

Aeroquip® by Danfoss
Metric Push to Connect Adapter - Cartridge

Quantity

Specifications for Variant SKU: 1161X6M Danfoss
Shape (Orientation):	Straight
Material(s):	Nickel Plated Brass
Seal Material(s):	Buna-N/Nitrile Rubber
Compatible with the following Series:	MTP160 Series

Applications:
Compressed air, pneumatic instrumentation, circuit, lubricant and cooling lines.
Advantages:
Ease of assembly. No tools required, reusability of fittings and the time savings of assembly and disassembly.
Used With:
MTP160 nylon tubing.
Material:
Brass, Nickel Plated O-Ring: Buna-N
Pressure:
Up to 250 psi depending on tube size.
Temperature Range:
-40°F to 200°F (-40°C to 93°C).

Nominal Size	2	4	5MM	6	8
Thread
MM (Metric Screw Thread)			M5x.8
BSPT	1/8 (2PT)	1/4 (4PT)		3/8 (6PT)	1/2 (8PT)
BSPP	1/8 (2PP)	1/4 (4PP)		3/8 (6PP)	1/2


Nickel Plated Brass Part Number	Tube OD (mm)	F	G	L	S	H	B
1161X6M	6mm	11.80mm	12.2mm	16.5mm	11.95mm	12.0mm	4.0mm

Danfoss (Eaton - Aeroquip)

Danfoss is a global technology leader in power management solutions that make electrical, hydraulic and mechanical power operate more efficiently, reliably, safely and sustainably. Danfoss hydraulic pumps, motors, transmissions, valves, cylinders, controls, hose and fittings offer a unique combination of proven technology and innovative design that translates directly into reliable performance and enhanced uptime.
