13/32" (-8) F204 Couplamatic -08 Refrigerant Hose - Two Fiber Braid, Internal Nylon Barrier - (R12 & R134A Compatible) - 13/32" ID - 725ft

13/32" (-8) F204 by Couplamatic | -08 Refrigerant Hose | Two Fiber Braid | Internal Nylon Barrier | R12 & R134A Compatible | 13/32" ID | 725ft

Save $12.89 Save $12.89
$2,255.56
$2,255.56 - $2,255.56
$2,255.56
$2,242.67
$2,242.67 - $2,242.67
$2,242.67

Couplamatic Systems Inc.
Two Fiber Braid - F204 Refrigerant Hose (R12 & R134A Compatible)

Package Quantity: 725 FT

Specifications for Variant SKU: 13/32" (-8) F204 Couplamatic | 725 |
Series: F204 Series
Hose Color(s): Black
Internal Diameter: 0.40625in
Outer Diameter: 0.91in
Cover Construction: Rubber
Applicable Specs & Approvals: Refrigerant R12 Compatible, Refrigerant R134A Compatible
Applications: Air Conditioning, Refrigerant SAE Rating: N/A
Cover: Rubber Reinforcement: Two Fiber Braid, Internal Nylon Barrier
Temperature: -22F to +257F (-30C to +125C)
Part Number Hose ID Hose OD Working Pressure
(lbs)		 Min. Burst Pressure
(lbs)		 Min. Bend Radius Weight per 100ft Coil Footage
5/16" (6) F204 5/16"(-06) 0.750" 500 lbs. 2,000 lbs. 4" 20 lbs. 825ft
13/32" (-8) F204 13/32"(-08) 0.910" 500 lbs. 2,000 lbs. 5" 28 lbs. 725ft
1/2" (-10) F204 1/2"(-10) 1.000" 500 lbs. 2,000 lbs. 5" 33 lbs. 700ft
5/8" (-12) F204 5/8"(-12) 1.130" 350 lbs. 1,750 lbs. 6" 38 lbs. 525ft
Couplamatic Systems Inc

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
