28320 (28-320) Midland Female x Male Pipe Bulkhead Fitting - 1/4-18 Female NPTF x 1/2-14 NPTF - 3-15/16" Length - Steel

28320 by Midland | Pipe Bulkhead Fitting | 1/4-18 Female NPTF x 1/2-14 NPTF | 3-15/16" Length | Steel

Save $3.45 Save $3.45
$31.01
$31.01 - $31.01
$31.01
$27.56
$27.56 - $27.56
$27.56

Midland Industries
Brass Fitting - Bulkhead Fitting - Female x Male Pipe Bulkhead Fitting

Inventory @ Manufacturers Warehouse: 85 Units
Specifications for Variant SKU: 28320 Midland
Shape (Orientation): Straight
Ends Configuration: 1/2in Male NPTF, 1/2in Male NPTF, Some Ends Match
Material(s): Steel
Applicable Specs & Approvals: Applicable ASA Standards, Applicable ASME Standards, Applicable SAE Standards
Applications: Grease, Fuels, LP and Natural Gas (available on special order), Refrigeration, Instrumentation and Hydraulic Systems Used With: Brass, Bronze, Copper, Steel, Aluminum and Iron Pipe
SAE Rating: N/A Conformance: Meets specifications and standards of ASA, ASME and SAE
Vibration: Fair Resistance. Temperature Range: -65°F to +250°F (-53°C to +121°C)
Tolerance: +/- .02 on all dimensions. Dimension Data can change without notice. Lead Free: Not Lead Free
Pipe Size 1/16" 1/8" 1/4" 3/8" 1/2" 3/4" 1"
Thread Size 1/16-27 1/8-27 1/4-18 3/8-18 1/2-14 3/4-14 1-11-1/2
Working Pressure 1200 PSI 1200 PSI 1200 PSI 1200 PSI 1200 PSI 1000 PSI 1000 PSI
Thread OD 1/4" 3/8" 1/2" 5/8" 3/4" 1" 1-1/4"
Part Number A B C Length (in.)
28312
(28-312)		 1/4-18 NPTF 1-14 UNS 1/2-14 NPTF 2.94"
28320
(28-320)		 1/4-18 NPTF 1-14 UNS 1/2-14 NPTF 3-15/16"
Midland Industries

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
