3/4" ULTRA R16 Couplamatic Import Ultra Two Wire Hi-Pressure High/Low Temp Hydraulic Hose (100R16 / DIN 2SC) - 3/4" ID - 250ft

3/4" ULTRA R16 by Couplamatic | Import Ultra Two Wire Hi-Pressure | High/Low Temp Hydraulic Hose | 100R16/DIN 2SC | 3/4" ID | 250ft

Save $276.83 Save $276.83
$2,491.50
$2,491.50 - $2,491.50
$2,491.50
$2,214.67
$2,214.67 - $2,214.67
$2,214.67

Couplamatic Systems Inc.
Two Wire Braid Hoses - ULTRA R16 Import Ultra Two Wire Hi-Pressure High/Low Temp Hydraulic Hose - ULTRA 100R16 / DIN 2SC

Package Quantity: 250 FT

Specifications for Variant SKU: 3/4" ULTRA R16 Couplamatic | 250 |
Series: Ultra R16 Series
Hose Color(s): Blue
Dash Size: -12
Internal Diameter: 0.75in
Outer Diameter: 1.090in
Applicable Specs & Approvals: EN857, Applicable MSHA Standards, SAE 100R16
Compatible with the following Series: A Series  |   Grip Crimp Series
Applications: High Pressure Hydraulics, High/Low Temp Applications SAE Rating: ULTRA 100R16 / DIN 2SC
Cover: Blue Abrasion and Flame Resistant Cover, MSHA approved Reinforcement: Two Wire Braids
Temperature: -58F to +275F (-50C to +135C)
(+302F/150C Discontinuous)
Part Number Hose ID Hose OD Working Pressure
(lbs)		 Min. Burst Pressure
(lbs)		 Min. Bend Radius Weight per 100ft Reel Footage
1/4" ULTRA R16 1/4" 0.530" 5,800 lbs. 23,200 lbs. 2" 18 lbs. 500ft
3/8" ULTRA R16 3/8" 0.687" 5,000 lbs. 20,000 lbs. 2.5" 27 lbs. 400ft
1/2" ULTRA R16 1/2" 0.812" 4,250 lbs. 17,000 lbs. 3.5" 35 lbs. 300ft
5/8" ULTRA R16 5/8" 0.937" 3,625 lbs. 14,500 lbs. 4" 40 lbs. 250ft
3/4" ULTRA R16 3/4" 1.090" 3,125 lbs. 12,500 lbs. 4.8" 54 lbs. 250ft
1" ULTRA R16 1" 1.405" 2,500 lbs. 10,000 lbs. 6" 74 lbs. 200ft

**Crimps to 100R1AT One Wire Thin Cover Specs - Tighter Bend Radius than R1 and R2 - High/Low Temp**
