3/8" HPIII Couplamatic 2-Wire Domestic Hi-Pressure Extremely Flexible Hydraulic Hose (SAE 100R16) - 3/8" ID - 250ft

3/8" HPIII by Couplamatic | 2-Wire Domestic Hi-Pressure Extremely Flexible Hydraulic Hose | SAE 100R16 | 3/8" ID | 250ft

Save $9.78

$911.11

$911.11 - $911.11

$911.11

$901.33

$901.33 - $901.33

$901.33

Couplamatic Systems Inc.
Two Wire Braid Hoses - HPIII Two Wire Domestic Hi-Pressure Extremely Flexible Hydraulic Hose - SAE 100R16

Package Quantity: 250 FT

Quantity

Specifications for Variant SKU: 3/8" HPIII Couplamatic \| 250 \|
Series:	HPIII Series
Hose Color(s):	Black
Dash Size:	-6
Internal Diameter:	0.375in
Outer Diameter:	0.693in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R16
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series

Applications:	High Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R16
Cover:	Abrasion and Flame Resistant Cover, MSHA Approved	Reinforcement:	Two Wire Braids
Temperature:	-40F to +212F (-40C to +100C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" HPIII	1/4"	0.541"	5,000 lbs.	20,000 lbs.	2"	18 lbs.	250ft
3/8" HPIII	3/8"	0.693"	4,000 lbs.	16,000 lbs.	2.5"	24 lbs.	250ft
1/2" HPIII	1/2"	0.823"	3,500 lbs.	14,000 lbs.	3.5"	31 lbs.	250ft
5/8" HPIII	5/8"	0.950"	2,750 lbs.	11,000 lbs.	4"	36 lbs.	250ft
3/4" HPIII	3/4"	1.103"	2,250 lbs.	9,000 lbs.	4.8"	49 lbs.	250ft
1" HPIII	1"	1.415"	2,000 lbs.	8,000 lbs.	6"	67 lbs.	250ft

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
