3108 60 13 by Parker | LF3000® Push-to-Connect Fittings | 3/8" Push-to-Connect x 3/8" Push-to-Connect x 1/4" Male BSPT Thread | 15 mm Hex | 2.08" Length | Tee | Polymer | Pack of 10

$79.94 - $79.94

$79.94

$87.33

$87.33 - $87.33

$87.33

by Parker Hannifin
LF 3000® Push-In Fittings / Stud Fittings:3108 - male branch tee fractional inch tube to male BSPT

Package Quantity: 10 Units

Quantity

Specifications for Variant SKU: 3108 60 13 Parker \| 10 \|
Brand:	LF 3000®
Series:	3108 Series
Shape (Orientation):	Tee
Material(s):	Nickel-Plated Brass, Stainless Steel, Polymer
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Silicone Free, Lightweight, Coated, Swivel

Technical Characteristics:	Compatible Fluids: Compressed air Working Pressure: Vacuum to 20 bar Working Temperature: -20°C to +80°C
Advantages:	Robust, lightweight, compact to build your pneumatic circuits Full flow connections to optimize flow rates Use in vacuum as well as in compressed air Customized products upon request. Please, contact us
Regulations:	ISO 14743 PED RoHS REACH
Component Materials:	Gripping Ring: Stainless Steel Body: Technical Polymer BSPP Thread Sealing: NBR O-Ring BSPT/NPT: Pre-coating Adaptor: Nickel-Plated Brass Sealing Ring: NBR Release Button Technical Polymer


Part Number	ØD	C	F	G	H	L/2	Kg
3108 53 10	1/8"	1/8"	10 mm	.34"	.61"	.55"	.0059 Kg
3108 04 10	4 mm	1/8"	10 mm	8.5 mm	15.5 mm	14 mm	.006 Kg
3108 04 13	4 mm	1/4"	14 mm	8.5 mm	16 mm	14 mm	.015 Kg
3108 55 10	3/16"	1/8"	11 mm	.43"	.67"	.85"	.0398 Kg
3108 55 13	3/16"	1/4"	14 mm	.43"	.67"	.85"	.0309 Kg
3108 56 10	1/4"	1/8"	10 mm	.43"	.67"	.71"	.0506 Kg
3108 56 13	1/4"	1/4"	14 mm	.43"	.63"	.71"	..575 Kg
3108 06 10	6 mm	1/8"	10 mm	10.5 mm	17.5 mm	16 mm	.007 Kg
3108 06 13	6 mm	1/4"	14 mm	10.5 mm	18 mm	16 mm	.016 Kg
3108 08 10	8 mm	1/8"	10 mm	13.5 mm	22 mm	23 mm	.009 Kg
3108 08 13	8 mm	1/4"	14 mm	13.5 mm	21 mm	23 mm	.016 Kg
3108 08 17	8 mm	3/8"	17 mm	13.5 mm	21 mm	23 mm	.020 Kg
3108 60 13	3/8"	3/4"	15 mm	.63"	.95"	1.04"	.068 Kg
3108 60 17	3/8"	3/8"	17 mm	.63"	.95"	1.04"	.068 Kg
3108 60 21	3/8"	1/2"	-	-	-	-	-
3108 10 13	10 mm	1/4"	15 mm	16 mm	24 mm	26.5 mm	.017 Kg
3108 10 17	10 mm	3/8"	17 mm	16 mm	24 mm	26.5 mm	.022 Kg
3108 10 21	10 mm	1/2"	21 mm	16 mm	24 mm	26.5 mm	.034 Kg
3108 62 21	1/2"	1/2"	-	-	-	-	-
3108 12 13	12 mm	1/4"	19 mm	27 mm	31 mm	021 mm	.021 Kg
3108 12 17	12 mm	3/8"	17 mm	19 mm	27 mm	31 mm	.027 Kg
3108 12 21	12 mm	1/2"	21 mm	19 mm	27 mm	31 mm	.041 Kg
3108 14 17	14 mm	3/8"	20 mm	22 mm	30.5 mm	35 mm	.038 Kg
3108 14 21	14 mm	1/2"	24 mm	22 mm	28.5 mm	35 mm	.049 Kg
3108 16 17	16 mm	3/8"	27 mm	27 mm	53 mm	38.5 mm	.128 Kg
3108 16 21	16 mm	1/2"	27 mm	27 mm	53 mm	38.5 mm	.124 Kg

Pre-coated thread

The body swivels for positioning purposes.
