365PLP-8M-10M by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Tube to Tube Fittings | 8mm to 10mm Unequal Union | 34.5mm Length (L) | 90° Elbow | Glass-Reinforced Nylon | Pack of 10

365PLP-8M-10M by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Tube to Tube Fittings | 8mm to 10mm Unequal Union | 34.5mm Length (L) | 90° Elbow | Glass-Reinforced Nylon | Pack of 10

Save $9.30 Save $9.30
$102.32
$102.32 - $102.32
$102.32
$93.02
$93.02 - $93.02
$93.02

by Parker Hannifin
Push-to-Connect Fittings:365PLP Unequal Union Elbow

Package Quantity: 10 Units

Specifications for Variant SKU: 365PLP-8M-10M Parker | 10 |
Series: 365PLP Series
Shape (Orientation): 90° Elbow
Material(s): Glass-Reinforced Nylon
Special Properties: Corrosion Resistance, Chemical Resistance, Silicone Free
Product Features:
  • Stainless steel grab ring
  • Glass-reinforced nylon 6.6 body
  • Nitrile D-seal
  • Nylon release button
  • Corrosion and chemical resistance
  • NPT, BSPT, BSPP, and metric threads
  • Silicone Free
Markets:
  • Pneumatic
  • Industrial
  • Robotic
  • Automation
  • Printing
  • Packaging
  • Textile
Compatible Media:
  • Compressed Air
  • Inert Gases
  • Vacuum
Pressure Range: Up to 290 PSI (19.9 bar) depending on tubing
Up to 260 PSI (17.9 bar) depending on tubing (3/16” size only)
Temperature Range: -4° to +175° F (-20° to +79.4° C)
5° to +155° F (-15° to +68.3° C) (3/16” size only)
Vacuum Rating: 28" Hg
Compatible Tubing:
  • Semi-rigid nylon
  • Polyurethane 95 Durometer Shore A*
  • Nylon
  • Fluoropolymer
  • Polyethylene
Part Number Tube Size 1 Tube Size 2 L
365PLP-4M-6M 4 mm 6 mm 22.5 mm
365PLP-6M-8M 6 mm 8 mm 29.5 mm
365PLP-8M-10M 8 mm 10 mm 34.5 mm
365PLP-10M-12M 10 mm 12 mm 40.5 mm
