3700X12 by Danfoss | Pipe Adapter | Female Tee | 3/4" Female NPTF x 3/4" Female NPTF x 3/4" Female NPTF | Brass
3700X12 by Danfoss | Pipe Adapter | Female Tee | 3/4" Female NPTF x 3/4" Female NPTF x 3/4" Female NPTF | Brass
3700X12 by Danfoss | Pipe Adapter | Female Tee | 3/4" Female NPTF x 3/4" Female NPTF x 3/4" Female NPTF | Brass
3700X12 by Danfoss | Pipe Adapter | Female Tee | 3/4" Female NPTF x 3/4" Female NPTF x 3/4" Female NPTF | Brass

3700X12 by Danfoss | Pipe Adapter | Female Tee | 3/4" Female NPTF x 3/4" Female NPTF x 3/4" Female NPTF | Brass

$29.60 - $29.60
$29.60
$29.60 - $29.60
$29.60

Aeroquip® by Danfoss
Pipe Adapter - Female Tee
Specifications for Variant SKU: 3700X12 Danfoss
Shape (Orientation): Tee
Ends Configuration: 3/4in Female NPTF, 3/4in Female NPTF, 3/4in Female NPTF, Some Ends Match
Material(s): Brass
Applications:
  • Grease, refrigeration, instrumentation and hydraulic systems.
Advantages:
  • Dryseal pipe threads (NPTF).
  • Fair Vibration Resistance.
Used With:
  • Brass, bronze and iron pipe.
Material:
  • CA360 Brass.
Operating Pressure:
  • Operating pressure up to 1200 psi.
Temperature Range:
  • -65°F to +250°F
    (-53°C to +121°C).
Conformance:
  • Ref. SAE No. 130438
  • Listed by Underwriters Laboratories (available on special order) for fuel equipment, refrigeration and gas. Meets specifications and standards of ASA, ASME and SAE.
Pipe Size 1/16" 1/8" 1/4" 3/8" 1/2" 3/4"
Thread Size 1/16-27 1/8-27 1/4-18 3/8-18 1/2-14 3/4-14
Brass
Part Number 		Female Pipe
Thread		 C D L L2
3700X2 1/8" 9/16" 0.339" 1.10" 0.55"
3700X4 1/4" 11/16" 0.438" 1.56" 0.78"
3700X6 3/8" 13/16" 0.562" 1.68" 0.84"
3700X8 1/2" 1" 0.703" 2.18" 1.09"
3700X12 3/4" 1-1/4" 0.906" 2.32" 1.16"
