3S-G-2U-GFBTSS Dixon Stainless Steel Bottom Mount Sanitary Pressure Gauge - 3-1/2" Dial Size - 2" Clamp Size - 0-300 PSI Range

Name: 3S-G-2U-GFBTSS Dixon Stainless Steel Bottom Mount Sanitary Pressure Gauge - 3-1/2" Dial Size - 2" Clamp Size - 0-300 PSI Range
Brand: Dixon
SKU: 3S-G-2U-GFBTSS Dixon
Price: 727.8 USD
Availability: InStock

Save $45.33

$773.13

$773.13 - $773.13

$773.13

$727.80

$727.80 - $727.80

$727.80

Dixon Sanitary Pressure Gauges
3-1/2" Gauge - 0-300 PSI Range - Stainless Steel

Quantity

Specifications for Variant SKU: 3S-G-2U-GFBTSS Dixon

Features:
Accuracy: ± 1.5% of full scale Over range capacity: 30% Wetted surfaces: 316L stainless steel Surface finishes (wetted parts): Ra max = 25 microinches Case material: 304 stainless steel Dial size: 3-1/2" Lens material: polycarbonate Temperature range: 0°F (-18°C) to 250°F (121°C) Standard fill: food grade glycerin Rezero feature: standard on pointer


Part Number	Dial Size	Clamp Size	Pressure Range (PSI)	Fill	Mount
3S-G-15U-GFBKSS	3-1/2"	1-1/2"	0-300 PSI	Glycerin	Back Mount
3S-G-15U-GFBTSS	3-1/2"	1-1/2"	0-300 PSI	Glycerin	Bottom Mount
3S-G-15U-NFBTSS	3-1/2"	1-1/2"	0-300 PSI	No Fill	Bottom Mount
3S-G-2I-GFBTSS	3-1/2"	2"	0-300 PSI	Glycerin	Bottom Mount
3S-G-2T-GFBTSS	3-1/2"	2"	0-300 PSI	Glycerin	Bottom Mount
3S-G-2U-GFBKSS	3-1/2"	2"	0-300 PSI	Glycerin	Back Mount
3S-G-2U-GFBTSS	3-1/2"	2"	0-300 PSI	Glycerin	Bottom Mount
3S-G-2U-GFRTSS	3-1/2"	2"	0-300 PSI	Glycerin	Right Mount
3S-G-2U-NFBTSS	3-1/2"	2"	0-300 PSI	No Fill	Bottom Mount

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
