4511-1001 by Jason Industrial | 4511 Series | FDA Braided Hose 125 PSI | 1" ID | 1.28" OD | Clear | PVC | 300ft

4511-1001 by Jason Industrial | 4511 Series | FDA Braided Hose 125 PSI | 1" ID | 1.28" OD | Clear | PVC | 300ft

Save $5.69 Save $5.69
$477.69
$477.69 - $477.69
$477.69
$472.00
$472.00 - $472.00
$472.00

Jason Industrial Inc. Hose - Food Hose - 4511 FDA Braided PVC Hose - Clear

Package Quantity: 300 FT

Specifications for Variant SKU: 4511-1001 Jason | 300 |
Series: 4511 Series
Hose Color(s): Clear/Semi-Clear
Internal Diameter: 1in
Outer Diameter: 1.28in
Tubing Construction: PVC
Cover Construction: PVC
Applicable Specs & Approvals: Applicable FDA Requirements

SPECIFICATIONS

Application: Food and beverage dispensing, potable water, air, breathing lines, packaging and equipment, lube lines and other visual flow applications. SAE Rating: N/A
Other Ratings: FDA Grade Tube and Cover Tube: Crystal Clear, Non-toxic FDA Grade PVC
Reinforcement: One Synthetic Braid Cover: Crystal Clear, Non-toxic FDA Grade PVC
Temperature Range: -14 deg. F (-26 deg. C) to +140 deg. F (+60 deg. C) Crimp Fittings: N/A
Reusable Fittings: N/A Branding: Jason logo WP (PSI) FDA NON-TOXIC, Country of Origin.
Other Features:
  • One piece coils
  • Resists chemical, ozone and weathering.
  • Capable of handling a wide variety of food products
Part Number I.D. O.D. Reinforcement Braids Max. Working Press. @ 68 deg. F Vacuum @ 68 deg. F Weight Min. Bend Radius Standard Length
in. mm in. mm PSI BAR inHg lb./ft. KG/m in. mm ft
Uncoupled
4511-0251 1/4" 6.35mm 0.45" 11.43mm 1 250 PSI 17.24 BAR N/A 0.04 lb./ft. 0.06 KG/m N/A N/A 300ft
4511-0311 5/16" 7.94mm 0.47" 11.94mm 1 250 PSI 17.24 BAR N/A 0.05 lb./ft. 0.07 KG/m N/A N/A 300ft
4511-0381 3/8" 9.53mm 0.55" 13.97mm 1 200 PSI 13.79 BAR N/A 0.07 lb./ft. 0.10 KG/m N/A N/A 300ft
4511-0501 1/2" 12.70mm 0.69" 17.53mm 1 150 PSI 10.35 BAR N/A 0.10 lb./ft. 0.15 KG/m N/A N/A 300ft
4511-0631 5/8" 15.88mm 0.82" 20.83mm 1 150 PSI 10.35 BAR N/A 0.12 lb./ft. 0.18 KG/m N/A N/A 300ft
4511-0751 3/4" 19.05mm 0.99" 25.15mm 1 150 PSI 10.35 BAR N/A 0.18 lb./ft. 0.27 KG/m N/A N/A 300ft
4511-1001 1" 25.40mm 1.28" 32.51mm 1 125 PSI 8.62 BAR N/A 0.27 lb./ft. 0.40 KG/m N/A N/A 300ft
4511-1251 1-1/4" 31.75mm 1.61" 40.89mm 1 100 PSI 6.89 BAR N/A 0.44 lb./ft. 0.65 KG/m N/A N/A 100ft
4511-1501 1-1/2" 38.10mm 1.85" 46.99mm 1 70 PSI 4.83 BAR N/A 0.51 lb./ft. 0.76 KG/m N/A N/A 100ft
4511-2001 2" 50.80mm 2.39" 60.71mm 1 60 PSI 4.14 BAR N/A 0.74 lb./ft. 1.10 KG/m N/A N/A 100ft
Working pressure is temperature dependent. Jason Industrial Inc. disclaims any liability for use of their products in applications other than which they are designed.
Jason Industrial

Jason Industrial

Founded in 1958 in Fairfield, NJ, Jason Industrial quickly gained a solid reputation as a go to source for both industrial hose and power transmission belts. Jason Industrial offers a comprehensive portfolio of industrial hose, couplings and accessories along with hydraulic hose, fittings and crimping equipment.
