4797-8-6B Aeroquip by Danfoss | Female Pipe Universal Socketless Reusable Hose Fitting | -08 Female JIC (Also Couples w/ SAE 45° Flare) x -06 Push-On Hose Barb | Brass
4797-8-6B Aeroquip by Danfoss | Female Pipe Universal Socketless Reusable Hose Fitting | -08 Female JIC (Also Couples w/ SAE 45° Flare) x -06 Push-On Hose Barb | Brass
4797-8-6B Aeroquip by Danfoss | Female Pipe Universal Socketless Reusable Hose Fitting | -08 Female JIC (Also Couples w/ SAE 45° Flare) x -06 Push-On Hose Barb | Brass
4797-8-6B Aeroquip by Danfoss | Female Pipe Universal Socketless Reusable Hose Fitting | -08 Female JIC (Also Couples w/ SAE 45° Flare) x -06 Push-On Hose Barb | Brass

4797-8-6B Aeroquip by Danfoss | Female Pipe Universal Socketless Reusable Hose Fitting | -08 Female JIC (Also Couples w/ SAE 45° Flare) x -06 Push-On Hose Barb | Brass

$19.52 - $19.52
$19.52
$19.52 - $19.52
$19.52

Aeroquip® by Danfoss
Socketless (Push-On Hose Barb) Reusable Hose Fitting - Male Pipe Universal - Straight

Male JIC also Couples with SAE 45° Flare.

Double notch in nut for Universal type identification for both SAE 45° and 37° (JIC) connections.

(Formerly Eaton Aeroquip)
Specifications for Variant SKU: 4797-8-6B Danfoss
Shape (Orientation): Straight
Ends Configuration: 1/2in Female JIC, 3/8in Push-On Hose Barb, 1/2in Female SAE 45 Flare
Material(s): Brass
Compatible with the following Series: 2556 Series  |   2565 Series  |   FC332 Series  |   FC647 Series  |   H201 Series
Technical Info:
Brass
Part Number 		Hose Size Thread A D EØ
4797-4B -04 7/16-20 1.55" 0.80" 0.17"
4797-5-4B -04 1/2-20 1.60" 0.84" 0.17"
4797-8-6B -06 3/4-16 1.89" 1.02" 0.30"
4797-8B -08 3/4-16 2.03" 1.02" 0.39"
4797-10B -10 7/8-14 2.68" 1.14" 0.48"
