5.0-C-SS by Texcel | CAM & GROOVE COUPLING LINE | Type C | 5" Female Coupler x 5" Hose Shank | Straight | Stainless Steel

5.0-C-SS by Texcel | CAM & GROOVE COUPLING LINE | Type C | 5" Female Coupler x 5" Hose Shank | Straight | Stainless Steel

Save $19.62 Save $19.62
$176.61
$176.61 - $176.61
$176.61
$156.99
$156.99 - $156.99
$156.99

Texcel
CAM & GROOVE COUPLING LINE Series | Type C Coupler
Specifications for Variant SKU: 5.0-C-SS Texcel
Series: CAM & GROOVE COUPLING LINE
Shape (Orientation): Straight
Cam Type: Type C
Ends Configuration: Cam & Groove, Hose Barb
Material(s): Stainless Steel
Description
Aluminum constructed Cam and Groove Type C female coupler by hose shank.
Hose Diameter Part Number Lbs./Each
3/4" .75-C-ALUM 0.26 lbs
1" 1.0-C-ALUM 0.45 lbs
1-1/4" 1.25-C-ALUM 0.70 lbs
1-1/2" 1.5-C-ALUM 0.75 lbs
2" 2.0-C-ALUM 1.04 lbs
2-1/2" 2.5-C-ALUM 1.47 lbs
4" 4.0-C-ALUM 2.94 lbs
6" 6.0-C-ALUM 6.39 lbs
8" 8.0-C-ALUM 13.00 lbs
3/4" .75-C-BRASS 0.46 lbs
1" 1.0-C-BRASS 0.73 lbs
1-1/4" 1.25-C-BRASS 1.15 lbs
2" 2.0-C-BRASS 1.91 lbs
2-1/2" 2.5-C-BRASS 2.94 lbs
4" 4.0-C-BRASS 5.07 lbs
5" 5.0-C-BRASS N/A
3/4" .75-C-SS 0.39 lbs
1" 1.0-C-SS 0.65 lbs
1-1/4" 1.25-C-SS 1.02 lbs
1-1/2" 1.5-C-SS 1.23 lbs
2" 2.0-C-SS 1.78 lbs
2-1/2" 2.5-C-SS 2.77 lbs
3" 3.0-C-SS 3.40 lbs
4" 4.0-C-SS 5.89 lbs
5" 5.0-C-SS 7.25 lbs
6" 6.0-C-SS 11.00 lbs
1" 1.0-C-CS N/A
2" 2.0-C-CS 1.78 lbs
3" 3.0-C-CS 3.88 lbs
7" 4.0-C-CS 5.89 lbs
