6310-1/2"-1/2" AIGNEP | Ball Valves Series | Ball Valve | 1/2" Female BSPT x 1/2" Male BSPT

6310-1/2"-1/2 by AIGNEP | Ball Valves Series | Ball Valve | 1/2" Female BSPT x 1/2" Male BSPT

Save $0.09 Save $0.09
$9.20
$9.20 - $9.20
$9.20
$9.11
$9.11 - $9.11
$9.11
Specifications for Variant SKU: 6310-1/2-1/2 AIGNEP
Series: Ball Valves Series
Shape (Orientation): Straight
Ends Configuration: 1/2in Female BSPT, 1/2in Male BSPT
Material(s): Chrome Plated Brass

Male x Female

Pressure Rating: Vacuum - 290 PSI
Temperature Range: 0-176° ° F
Media: Air, oil, water, gas (Consult factory for seal compatibility)
Body: Chrome Plated Brass
Thread Type: BSPT

Product Number A NPTF Color Plate Thread Type F L B NPTF IN Orifice Es C F H
6310-1/8-1/8 1/8" Composite BSPT 0.295" 36 mm 1/8" 5.5 mm 14 mm 19 mm 7.5 mm 21 mm
6310-1/4-1/4 1/4" Composite BSPT 0.433" 43 mm 1/4" 5.5 mm 14 mm 19 mm 11 mm 21 mm
6310-3/8-3/8 3/8" Composite BSPT 0.452" 46 mm 3/8" 8 mm 18 mm 19 mm 11.5 mm 22 mm
6310-1/2-1/2 1/2" Composite BSPT 0.590" 57 mm 1/2" 10 mm 22 mm 26 mm 15 mm 30.5 mm
AIGNEP

AIGNEP

For over 40 years, AIGNEP has been a leading manufacturer of compressed air and industrial fluid fittings. Our products are widely known for their high quality and Italian design: pneumatic cylinders and solenoid valves, fluid process control valves “FLUIDITY”, compressed air pipeline “INFINITY”, fittings and quick couplings for every fluid media.
