68PLPR-2-0 by Parker | Prestolok PLP Push-to-Connect Fittings | Threaded Fitting | 1/8" Round Body Connector x 10-32" Male UNF Thread | 3/32" Hex | Straight | Nickel-Plated Brass | Pack of 10

68PLPR-2-0 by Parker | Prestolok PLP Push-to-Connect Fittings | Threaded Fitting | 1/8" Round Body Connector x 10-32" Male UNF Thread | 3/32" Hex | Straight | Nickel-Plated Brass | Pack of 10

Save $7.41 Save $7.41
$81.48
$81.48 - $81.48
$81.48
$74.07
$74.07 - $74.07
$74.07

by Parker Hannifin
Push-to-Connect Fittings:68PLPR Round Male Connector – NPTF/UNF

Package Quantity: 10 Units

Specifications for Variant SKU: 68PLPR-2-0 Parker | 10 |
Series: 68PLPR Series
Shape (Orientation): Straight
Material(s): Nickel-Plated Brass, Stainless Steel, PVDF
Seal Material(s): Buna-N/Nitrile Rubber
Special Properties: Corrosion Resistance, Flame Resistant Release Button
Product Features:
  • Stainless steel grab ring
  • Nickel-plated brass body
  • Nitrile seal
  • Flame resistant release button
  • Corrosion resistance
  • Inch and metric tube connections
  • NPT, BSPP, BSPT, and metric threads
  • Meets UL94 V-0 Flame Resistance Standard
Markets:
  • Industrial
  • Automotive
  • Climate Control
  • Welding
  • Robotic Welding
Compatible Media:
  • Compressed Air
  • Inert Gases
  • Vacuum
Pressure Range: Up to 300 PSI (20.6 bar) depending on tubing
Temperature Range: 0° to +200° F (-17.7° to 93.3° C)
Vacuum Rating: 28" Hg
Compatible Tubing:
  • 95FR Microweld
  • Polyethylene
  • Polypropylene
  • Semi Rigid Nylon
  • Rigid Nylon
  • Polyurethane 95 Durometer Shore A
Part Number Tube Size Thread Size NPTF Internal Hex Broach Body Diameter O.D. Length (L) Flow Diameter
68PLPR-2-0* 1/8" 10-32 3/32" 3/8" .89" .094"
68PLPR-5/32-0* 5/32" 10-32 3/32" 3/8" .97" .094"
68PLPR-4-0* 1/4" 10-32 3/32" 1/2" .95" .094"
W68PLPR-5/32-1 5/32" 1/16" 1/8" 3/8" .87" .125"
W68PLPR-5/32-2 5/32" 1/8" 1/8" 7/16" .79" .125"
W68PLPR-4-1 1/4" 1/16" 5/32" 1/2" 1.06" .156"
W68PLPR-4-2 1/4" 1/8" 3/16" 1/2" .88" .188"
W68PLPR-4-4 1/4" 1/4" 3/16" 5/8" .99" .188"

*10-32 seal is neoprene
