7815 11 11 by Parker | Threaded Port Knobless Meter Out Flow Control | 1/8" Male NPT Thread x 1/8" Female NPT Thread | 1.70" Length | 90° Elbow | Stainless Steel

7815 11 11 by Parker | Threaded Port Knobless Meter Out Flow Control | 1/8" Male NPT Thread x 1/8" Female NPT Thread | 1.70" Length | 90° Elbow | Stainless Steel

Save $8.54 Save $8.54
$117.38
$117.38 - $117.38
$117.38
$108.84
$108.84 - $108.84
$108.84

by Parker Hannifin
Stainless Steel Flow Controls:7810, 7812, 7815, 7817 Threaded Port Knobless Stainless Steel Flow Control - NPT, UNF
Specifications for Variant SKU: 7815 11 11 Parker
Shape (Orientation): 90° Elbow
Material(s): Stainless Steel
Seal Material(s): FKM
Special Properties: Food Grade, Valved, Flow Control
Product Features:
  • Suitable for corrosive environments
  • Excellent mechanical and chemical resistance
  • 100% leak tested in production
  • Smooth external surfaces to facilitate cleaning
  • Suitable for food applications
Markets:
  • Factory/Process Automation
  • Life Science
  • Food Processing
  • Water And Beverage
  • Petrochemical
Applications:
  • Packaging
  • Filling
  • Dispensing
  • Bottling
  • Pneumatic Circuits
  • Semi-Conductors
Pressure Range: 15 to 145 psi (1.0 to 9.9 bar)
Temperature Range: +32° to +158° F (0 to +70° C)
Compatible Tubing:
  • Polyethylene
  • 95FR
  • Polyurethane 95 Durometer Shore A
  • Semi-rigid Nylon
  • FEP Fluoropolymer
Part No. Meter Out C E E1 F H J L WT. OZ.
7810 20 20 10-32" .16" .16" 8 mm .94" .35" .43" .95"
7815 11 11 G1/8" .20" .31" 13 mm 1.50" .59" .67" 1.23"
7815 14 14 G1/4" .31" .47" 17 mm 1.38" .71" .94" 1.69"
7815 18 18 G3/8" .28" .55" 20 mm 1.89" .87" 1.06" 2.08"
