9114 18 17 by Parker | Legris Coupler Quick Disconnect | 3/8" Female BSPP | 19 mm Hex | 57 mm Length | Straight | Nickel-Plated Brass

9114 18 17 by Parker | Legris Coupler Quick Disconnect | 3/8" Female BSPP | 19 mm Hex | 57 mm Length | Straight | Nickel-Plated Brass | Pack of 5

Save $142.67 Save $142.67
$356.67
$356.67 - $356.67
$356.67
$214.00
$214.00 - $214.00
$214.00

by Parker Hannifin
Series 18 - Brass/Steel:9114 Coupler with valve, Female Thread

Package Quantity: 5 Units

Specifications for Variant SKU: 9114 18 17 Parker | 5 |
Series: 18 Series
Shape (Orientation): Straight
Material(s): Nickel-Plated Brass, Nickel-Plated Steel
Seal Material(s): Buna-N/Nitrile Rubber
Series 18 - Brass/Steel Series: Single Shut-Off Robust industrial coupling according to ISO 6150 C. Coupling system with single-hand operation. High Flow valve for optimum flow and low pressure drop. The steel sleeve counters oscillating forces. System has limited use for liquids (steel sleeve/zinc die cast valve). The high insertion depth guarantees by an optimized plug guidance.
      Available on request:
  • with additional end connections
  • other seals for different temperature ranges and fluids
Working Pressure:
  • up to 35 bar
Material:
  • Coupling: Nickel-Plated Brass / steel
  • Plug: Nickel-Plated Steel
  • Seals: NBR
Working Temperature:
  • -20°C up to +100°C (NBR)
Flow Rate Air:
  • 970 l/min. (inlet pressure 6 bar, pressure dop 0.5 bar)
Flow Rate Water:
  • 12.7 l/min. (Pressure dop 0.5 bar)
Part Number A Hex L L1 D
9114 18 17 3/8" 19 mm 57 mm 9 mm 23 mm

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
