941157LF Midland Lead Free Ball Valve - 1-1/2" Female NPT x 1-1/2" Female NPT - Brass

941157LF by Midland | Lead Free Ball Valve | 1-1/2" Female NPT x 1-1/2" Female NPT | Brass

Save $3.72 Save $3.72
$52.19
$52.19 - $52.19
$52.19
$48.47
$48.47 - $48.47
$48.47

Midland Industries
Lead Free Ball Valve - Full Port - Female NPT x Female NPT - Brass

Inventory @ Manufacturers Warehouse: 967 Units
Specifications for Variant SKU: 941157LF Midland
Shape (Orientation): Straight
Ends Configuration: 1-1/2in Female NPT, 1-1/2in Female NPT, Some Ends Match
Material(s): Lead Free Brass
Applicable Specs & Approvals: NSF 61, NSF 372, IGC-157, Lead Free as per the Safe Drinking Water Act
Special Properties: Lead Free
Features:
  • Lead Free and dezincification resistant (DZR) material
  • Vacuum Services 29.92 inches Hg
  • 600 psi (WOG) 150 psi (WSP) Service
  • Temperature Range : -40° F to 365° F
  • Made in China
  • Lead Free Lead Free Info (PDF)
Construction:
  • Forging Brass Body
  • PTFE Ball Seats
  • Blow Out Proof Brass Stem
  • Stainless Steel Ball
  • Steel Handle with Vinyl Grip
Specifications:
  • IAMPO IGC 157 - 2004b
  • IAPMO listed to NSF/ANSI-61, NSF/ANSI-372 ,IGC-157
  • CSA listed to NSF/ANSI-61, NSF/ANSI-372 ,IGC-157
  • Threads conform to ANSI B1.20.1
Part Number Size DN A B C E F G H Weight
lbs
941151LF
 1/4" 0.394 1.73" 1.69" 3.35" 0.453" 0.945" 2.154" 4.331" 0.32
941152LF
 3/8" 0.394 1.73" 1.69" 3.35" 0.473" 0.945" 2.154" 4.331" 0.32
941153LF
 1/2" 0.524 1.89" 1.73" 3.35" 0.472" 1.083" 2.276" 4.291" 0.36
941154LF
 3/4" 0.748 2.28" 1.89" 3.35" 0.563" 1.378" 2.579" 4.488" 0.57
941155LF
 1" 0.984 2.80" 2.14" 4.29" 0.650" 1.772" 3.031" 5.689" 0.94
941156LF
 1-1/4" 1.240 3.15" 2.32" 4.29" 0.669" 2.165" 3.398" 5.866" 1.30
941157LF
 1-1/2" 1.476 3.44" 2.66" 5.53" 0.701" 2.50" 3.909" 7.343" 1.92
941158LF
 2" 1.949 4.06" 3.01" 5.53" 0.708" 3.244" 4.638" 7.638" 3.12
941159LF
 2-1/2" 2.52 5.53" 4.25" 7.76" - - - - 7.42
941160LF
 3" 2.89 6.14" 4.58" 8.19" - - - - 11.01
941161LF
 4" 3.84 7.79" 5.49" 9.25" - - - - 12.10
Midland Industries

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
