B24RGC16-G200 Dixon Valve 304 Stainless Steel Hex Hanger with Nitrile Grommets & All Thread Coupler - 2" Tube OD

Name: B24RGC16-G200 Dixon Valve 304 Stainless Steel Hex Hanger with Nitrile Grommets & All Thread Coupler - 2" Tube OD
Brand: Dixon
SKU: B24RGC16-G200 Dixon
Price: 24.2 USD
Availability: InStock

Save $5.67

$29.87

$29.87 - $29.87

$29.87

$24.20

$24.20 - $24.20

$24.20

Dixon Sanitary Fittings Sanitary Hex Hanger with Nitrile Grommets and All Thread Coupler - 304 Stainless Steel

Max temperature: 230°F (110°C)

Quantity

Specifications for Variant SKU: B24RGC16-G200 Dixon

Features:
Coupler is all thread 3/8-16
Installation:
Straight sections need support every 10 ft. Each side of every valve (as close as possible to the connection) needs support. Support each change of directions.

Part Number	Tube OD	Weight (Lbs.)
B24RGC16-G75	3/4"	0.4850
B24RGC16-G100	1"	0.4700
B24RGC16-G150	1-1/2"	0.5550
B24RGC16-G200	2"	0.3590
B24RGC16-G250	2-1/2"	0.7200
B24RGC16-G300	3"	0.8500
B24RGC16-G400	4"	0.9950
B24RGC16-G600	6"	-
B24RGC16-G800	8"	-
