ET2B64G39 by RuB Inc. | Standard Actuation Kit | S64(39) Ball Valve | with ET 120 VAC Electric Actuator | Size 1-1/4" | Brass

Save $85.65

$770.86

$770.86 - $770.86

$770.86

$685.21

$685.21 - $685.21

$685.21

RuB Inc. - Standard Actuation Kits - Electric Actuators - S64(39) Brass Ball Valve with ET 120 VAC Electric Actuator

Quantity

Specifications for Variant SKU: ET2B64G39 RuB Inc
Shape (Orientation):	Straight
Material(s):	Brass

Assumptions:
1. ET Electric Actuators Torque ratings: ET-1 = 150 in lb., ET-2 = 300 in lb., CP = 44 in lb. 2. Media in valve other than slurry/liquids with abrasive material. 3. All RuB brass and SS valves with electric actuator assemblies are direct mount (no bridging, bracketing or adaptors) 4. ET actuators standard is 120 VAC. CP actuators are either 110 VAC or 24 VAC. 5. S64(39) and S64(LT) ball valves equipped with SS Trim. S31 and S74 brass ball valves equipped with brass trim. 6. Average time to turn 90 degrees: ET-1 = 2.5 sec, ET-2 = 6 sec, CP = 15 sec. 7. Duty Cycles: ET-1 & ET-2 = 50% rated duty cycle. CP = 60% rated duty cycle. 8. S64LT, S73 and S72 brass ball valves are full port. S31 and S74 brass ball valves are standard port. For other configurations, please contact Customer Service.

Part Number	Size
ET1B64D39	1/2"
ET1B64E39	3/4"
ET1B64F39	1"
ET2B64G39	1-1/4"
ET2B64H39	1-1/2"
ET2B64I39	2"

RuB Inc

RuB is a manufacturer of shut-off brass valves with focus on ball valves for gas, water, air, oil installations. Great emphasis is put on quality: ISO 9001 and PED compliance are guaranteed by well known organizations and many major international manufacturers rely on RuB. Our products are designed with long life and reliability criteria.
