BZAR-3.0 by Texcel | BALTHAZAR PLUS™ Series | Winery Hose | 3" Hose ID | 250 PSI | 29 in/Hg Vacuum Rated | Gray

$39.90 - $3,325.50

$39.90

$35.47

$35.47 - $2,956.00

$35.47

Texcel
BALTHAZAR™ PLUS Series | Winery Hose

Quantity

Specifications for Variant SKU: BZAR-3.0-100 Texcel \| 100 \|
Series:	BALTHAZAR PLUS™ Series
Hose Color(s):	Gray
Internal Diameter:	3in
Outer Diameter:	3.81in
Tubing Construction:	Bromobutyl Rubber
Cover Construction:	EPDM

Technical Data:
Description:	BALTHAZAR™ Plus winery hose is a smooth covered hose formulated for the suction and delivery of wine, fruit juice, and soft drinks. The BALTHAZAR™ Plus hose has a white, smooth Butyl tube to ensure food quality and is odorless and does not alter taste. Its high working temperature allows for the sterilization of the hose with steam at 230ºF for 30 minutes. Meets FDA title 21 part.177.2600(e) for liquid foods, BfR, ADI free, EC 1935 / 2004.	Tube:	White, Butyl
Cover:	Gray, EPDM	Reinforcement:	High strength synthetic plies with polyethylene spiral helix
Safety Factor:	3:1	Temperature:	-30°F to +220°F
Branding:	TEXCEL® BALTHAZAR™ PLUS WINERY HOSE 250 PSI (17BAR)	W.P. TEMP.:	-30F TO +220F (-34C TO 104C) STERILIZATION AT 230F FOR 30 MINS FDA BFR ADI FREE
Safety Note:	It is recommended that all food grade hose be thoroughly flushed prior to initial use	Features:	FDA, USDA compliant

Part Number	Hose ID	Hose OD	Working Pressure (psi)	Vacuum (in./HG)	Bend Radius	Lbs./Ft.
BZAR-1.5	1-1/2"	2-4/64"	250 psi	29	5"	0.93 lbs
BZAR-2.0	2"	2-40/64"	250 psi	29	9"	1.26 lbs
BZAR-3.0	3"	3-52/64"	250 psi	29	10"	2.02 lbs
