CFR47-1-200 Dixon Continuous Flow Reel - 1-1/2" Female NPT Inlet Size x 1-1/2" Male NST(NH) Outlet - Capacity: 400' of 3/4" Hose, 300' of 1" Hose, 150' of 1-1/2" Hose

CFR47-1-200 Dixon Continuous Flow Reel - 1-1/2" Female NPT Inlet Size x 1-1/2" Male NST(NH) Outlet - Capacity: 400' of 3/4" Hose, 300' of 1" Hose, 150' of 1-1/2" Hose

Save $223.86 Save $223.86
$1,716.31
$1,716.31 - $1,716.31
$1,716.31
$1,492.45
$1,492.45 - $1,492.45
$1,492.45

Dixon Fire Fittings
Fire Hose - Racks & Reels - Continuous Flow Reel

Allows immediate and continuous flow of water at all times during deployment of hose.
Specifications for Variant SKU: CFR47-1-200 Dixon
Features:
  • One-person operation.
  • Use with non-collapsible hose.
  • Powder coated with an electrostatically-applied, thermally-fused, red polyester finish steel drum.
  • Rims and universal mounting stand.
  • Female NPT inlet with male NST (NH) hose thread outlet.
Note:
  • A flexible connector assembly must be installed directly between the hose reel inlet hub and the water supply. Failure to use the flexible connector assembly will void the warranty.
Part Number Female NPT
Inlet Size		 Male NST(NH)
Outlet Size		 Hose Size and Capacity Dimensions Weight
(Lbs.)		 Vinyl Cover
3/4" 1" 1-1/2" A B C D E F G
CFR47-1-100 1" 1" 150ft 125ft - 10-1/2" 11-1/2" 24" 19-1/4" 24" 21-3/4" 26" 88.0000 CFR47-C1
CFR47-150-100 1-1/2" 1-1/2" 250ft 150ft 100ft 10-1/2" 20-1/2" 24" 28-1/4" 33" 21-3/4" 26" 60.0000 CFR47-C3
CFR47-1-200 1-1/2" 1-1/2" 400ft 300ft 150ft 10-1/2" 28" 24" 35-3/4" 40-1/2" 21-3/4" 26" 111.0000 CFR47-C2
CFR47-150-200 1-1/2" 1-1/2" - - 200ft 10-1/2" 34" 24" 41-3/4" 46-1/2" 21-3/4" 26" 100.5000 CFR47-C4
Optional Accessories
Part Number Description Weight
DX2836 1" x 18" flexible connector (male NPT x male NPT) 1.1100
DX2839 1-1/2" x 18" flexible connector (male NPT x male NPT) 2.0200
CFR-HC Hand Crank 1.7300
CFR-RK Repair Kit, Contains:
- O-ring
- PTFE retaining ring for the inlet casting
- Spacer washer
- 2 Steel retaining rings for the manifold		 1.2390
