CFS800-6CS Dixon King Crimp® | Short Frac Ferrule | 9.250" Ferrule ID | for Hose OD from 9-5/64" to 9-12/64" | Carbon Steel

CFS800-6CS Dixon King Crimp® | Short Frac Ferrule | 9.250" Ferrule ID | for Hose OD from 9-5/64" to 9-12/64" | Carbon Steel

Save $8.63 Save $8.63
$102.18
$102.18 - $102.18
$102.18
$93.55
$93.55 - $93.55
$93.55

Dixon Valve & Coupling
King Crimp® Style | Short Frac Ferrule

For use with Dixon Frac Fittings and King Crimp® Style Short Combination Nipples.
Specifications for Variant SKU: CFS800-6CS Dixon
Brand: King Crimp®
Material(s): Carbon Steel
Material:
  • Carbon Steel
Safety Notes:
  • Due to differences in dimensions and tolerances for safety reasons, do not interchange other manufacturer's products with Dixon products.
Carbon Steel
Part Number		 Hose I.D. Fits Hose O.D Ferrule Wall Thickness Ferrule I.D. Ferrule Overall Length
From To
CFS800-1CS 8" 8-29/64" 8-36/64" .120" 8.625" 4.25"
CFS800-2CS 8" 8-37/64" 8-44/64" .120" 8.750" 4.25"
CFS800-3CS 8" 8-45/64" 8-52/64" .120" 8.875" 4.25"
CFS800-4CS 8" 8-53/64" 8-60/64" .120" 9.000" 4.25"
CFS800-5CS 8" 8-61/64" 9-4/64" .120" 9.125" 4.25"
CFS800-6CS 8" 9-5/64" 9-12/64" .120" 9.250" 4.25"
CFS800-7CS 8" 9-13/64" 9-20/64" .120" 9.375" 4.25"
CFS800-8CS 8" 9-21/64" 9-28/64" .120" 9.500" 4.25"
