DG1000 by Dixon Valve | General Purpose Digital Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-1000 PSI Range | ABS Plastic

Save $40.92

$573.67

$573.67 - $573.67

$573.67

$532.75

$532.75 - $532.75

$532.75

Dixon Valve
Dixon® Gauge | Welding Gauge | Lower Mount

General purpose digital gauges are suitable for dry air applications and other media; gauge offers selectable units of measure so rather than purchasing one gauge for each unit of measure required; one gauge can be used for multiple units of measure.

Ideal for test applications and for use in technicians' tool kits.

Quantity

Specifications for Variant SKU: DG1000 Dixon
Series:	DG Series

Features:
0.5% terminal point accuracy. Five-digit LCD display with large size .48" characters. Bar graph display (20 segment). Nine engineering units (accessed through keypad): PSI, in. HG, cm Hg, mm Hg, KPA, Mpa, BAR, KG/cm2, ft H20. IP67 weatherproof enclosure, polycarbonate / ABS. Two AA alkaline batteries included. 2,000 hour minimum battery life.
Materials:
Wetted parts: 17-4 PH stainless steel sensor with 316L stainless steel socket.
Specifications:
Operating temperature: -4°F to 140°F (-20°C to 60°C) Polycarbonate window

2-1/2" Face 1/4" Lower Mount Part Number	PSI Range
DG100	0-100 PSI
DG300	0-300 PSI
DG1000	0-1000 PSI
DG10000	0-10000 PSI
