FBM3113 Eaton Aeroquip® Quick-Disconnect Radiator/Cooling Refill Coupling - 1/2" Female Thread - Steel

FBM3113 Eaton Aeroquip® Quick-Disconnect Radiator/Cooling Refill Coupling - 1/2" Female Thread - Steel

$22.69 - $22.69
$22.69
$24.16
$24.16 - $24.16
$24.16

Eaton Aeroquip® High Performance
Quick-Disconnect Radiator/Cooling Refill Coupling

Female Half:

  • Aluminum female quick disconnect coupling is 50% lighter than standard version.
  • Viton seals allows higher temperatures.
  • Stainless steel internal components significantly increase corrosion resistance.
  • Blue anodized 6061 aluminum body.
  • Easy connect/disconnect with positive locking.

Male Half:

  • Replacing previous carbon steel components with stainless steel material significantly improve the corrosion resistance of the popular coupling.
  • Red anodized 6061 aluminum body.
  • 54% lighter than standard steel version.
  • Viton seals allows higher temperatures.
Specifications for Variant SKU: FBM3113 Eaton HP
Shape (Orientation): Straight
Material(s): Carbon Steel
Seal Material(s): Viton/FKM
Quick-Disconnect Radiator/Cooling Refill Couplings
Steel
Part Number		 Material Description Working
Pressure		 Temperature Weight Seal Material
FBM1153 Red Anodized Aluminum Male Quick Disconnect Coupling 250 PSI -15°F to +300° F 1.73 oz Viton
FBM3113 Steel Female Quick Disconnect Coupling 250 PSI -15°F to +300° F 1.60 oz Viton
FBM3114 Blue Anodized Aluminum Female Quick Disconnect Coupling 250 PSI -15°F to +300° F 3.97 oz Viton

Warning: Do not mix and match hose and fitting manufactures with your hose assemblies. Each manufacturer of hose and fittings builds their product to specific tolerances and does not recommend them for use with other brands. Doing this puts your performance at risk and voids any warranty on your product.

Danfoss High Performance

Danfoss High Performance

For more than 80 years, Aeroquip Performance Products has been the number one choice of racing enthusiasts around the world. We engineer and test each hose length and fitting to stringent factors of safety and our hoses and fittings are tested to work together as an assembly ensuring a proper fit. 100% of our hose is made in the USA and all of our fittings and adapters are distributed from our warehouse in Van Wert, OH.
