FF9863-06S Aeroquip by Danfoss | Female O-Ring Face Seal (ORS) Cap | -06 Size | Steel

FF9863-06S Aeroquip by Danfoss | Female O-Ring Face Seal (ORS) Cap | -06 Size | Steel

Name: FF9863-06S Aeroquip by Danfoss | Female O-Ring Face Seal (ORS) Cap | -06 Size | Steel
Brand: Danfoss/Eaton
SKU: FF9863-06S Danfoss
Price: 3.18 USD
Availability: InStock

$3.18 - $3.18

$3.18

$3.18 - $3.18

$3.18

Aeroquip® by Danfoss
Female O-Ring Face Seal (ORS) Cap

(Formerly Eaton Aeroquip)

Specifications for Variant SKU: FF9863-06S Danfoss
Shape (Orientation):	No Orientation
Ends Configuration:	3/8in Female O-Ring Face Seal
Material(s):	Steel

Specifications:
Ref. SAE 520112
Construction:
Buna-N O-Rings are standard.


Steel Part Number	Tube OD	Thread T1	A	D	Hex 1
FF9863-04S	0.25"	9/16-18	0.66"	0.32"	0.69"
FF9863-06S	0.38"	11/16-16	0.75"	0.38"	0.81"
FF9863-08S	0.50"	13/16-16	0.90"	0.43"	0.94"
FF9863-10S	0.63"	1-14	1.00"	0.53"	1.12"
FF9863-12S	0.75"	1-3/16-12	1.10"	0.57"	1.38"
FF9863-16S	1.00"	1-7/16-12	1.17"	0.58"	1.62"
FF9863-20S	1.25"	1-11/16-12	1.17"	0.58"	1.88"
FF9863-24S	1.50"	2-12	1.17"	0.58"	2.25"
