GL110 by Dixon Valve | Compound Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-160 PSI Range | ABS Plastic

$15.48 - $15.48

$15.48

$20.56

$20.56 - $20.56

$20.56

Dixon Valve
Dixon® Gauge | Compound Gauge | Lower Mount

Designed for long, reliable service under rugged conditions.

Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement.

Quantity

Specifications for Variant SKU: GL110 Dixon
Series:	GL Series

Features:
ASME B40.1, Grade B accuracy (± 3-2-3 % accuracy).
Materials:
Case: ABS plastic, corrosion resistant Bourdon tube: bronze Socket: brass Window: poly carbonate Pointer: black aluminum Movement: powerflex with polyester segment, designed for extended wear
Specifications:
Temperature range of -40°F to 150°F (-40°C to 66°C)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

2-1/2" Face 1/4" Center Back Mount Part Number	2-1/2" Face 1/4" Lower Mount Part Number	Mercury (Hg)	PSI Range	Figure Interval (Hg / PSI)	Minor Gradient (Hg / PSI)
	GL310	30"	0-100 PSI	30 / 10	5 / 2
GL210		30"	0-160 PSI	30 / 20	5 / 5
	GL110	30"	0-160 PSI	30 / 20	10 / 10
	GL315	30"	0-200 PSI	30 / 20	10 / 10
