GRA400 by Kuriyama | Quick-Acting Coupling | Part A | 4" Male Adapter x 4" Female NPT | Nylon

GRA400 by Kuriyama | Quick-Acting Coupling | Part A | 4" Male Adapter x 4" Female NPT | Nylon

Save $0.76 Save $0.76
$27.33
$27.33 - $27.33
$27.33
$26.57
$26.57 - $26.57
$26.57

Kuriyama Couplings™ - Quick-Acting Couplings - Part A - Male Adapter x Female NPT - Nylon

Specifications for Variant SKU: GRA400 Kuriyama
Shape (Orientation): Straight
Cam Type: Type A
Ends Configuration: 4in Male Cam & Groove, 4in Female NPT
Material(s): Nylon
Applications:
  • Agriculture, Chemicals/Petroleum, Construction, Fracking, Irrigation, Material Handling
  • For use with Kuriyama Hoses
Features:
  • All sizes comply with Mil-Spec A-A-59326 for interchangeability.
  • Nylon material is fiberglass reinforced for high tensile strength and durability.
  • Locking feature using safety clips to prevent disconnection during use on all sizes.
  • All 4" size female couplers are supplied with three locking handles to provide added stability.
Materials:
  • Type 304 stainless steel handles.
  • Type 304 stainless steel handle pins.
  • Type 304 stainless steel pull rings.
  • Type 304 stainless steel safety clips.
  • EPDM gaskets.
Part Number Size Weight (Lbs.)
GRA100 1" x 1" 0.16 lbs.
GRA150 1-1/2" x 1-1/2" 0.18 lbs.
GRA200 2" x 2" 0.26 lbs.
GRA300 3" x 3" 0.46 lbs.
GRA400 4" x 4" 0.92 lbs.
Kuriyama

Kuriyama

Located in Schaumburg, Illinois, Kuriyama of America has been eminently successful in developing and marketing a complete line of thermoplastic hose and accessories. Their expansive product line consist of thermoplastic, rubber and metal hose products, along with accessories including couplings and fittings.
