KLOC-SS-D300 by Kuriyama | Quick-Acting Coupling K-Loc™ Auto Lock | Part D | 3" Female Coupler x 3" Female NPT | 316 Stainless Steel

KLOC-SS-D300 by Kuriyama | Quick-Acting Coupling K-Loc™ Auto Lock | Part D | 3" Female Coupler x 3" Female NPT | 316 Stainless Steel

$195.17 - $195.17
$195.17
$197.60
$197.60 - $197.60
$197.60

Kuriyama Couplings™ - Quick-Acting Couplings - K-Loc™ Auto Lock - Part D - Female Coupler x Female NPT - 316 Stainless Steel

Specifications for Variant SKU: KLOC-SS-D300 Kuriyama
Shape (Orientation): Straight
Cam Type: Type D
Ends Configuration: 3in Female Cam & Groove, 3in Female NPT
Material(s): 316 Stainless Steel, 304 Stainless Steel
Seal Material(s): Buna-N/Nitrile Rubber
Applications:
  • Agriculture, Chemicals/Petroleum, Construction, Material Handling, Irrigation, Fracking.
  • For use with Kuriyama Hoses
Features:
  • All sizes except 1/2" and 5" comply with Mil-Spec A-A-59326 for material and interchangeability.
  • 5" Size complies with ASTM specs for interchangeability.
  • 1/2" x 1/2" are not specified under Mil Specs.
  • Stainless steel alloy chemical composition is analyzed on every melt.
  • Composition test certificate is available upon request.
  • Locking feature using safety clips to prevent disconnection during use on all sizes except 1/2".
Materials:
  • ASTM A666 316 stainless steel alloy
  • Type 304 stainless steel handles
  • Type 304 stainless steel handle pins
  • Type 304 stainless steel pull rings
  • Type 304 stainless steel safety clips
  • Buna-N Gaskets
Part Number Female Coupler Female NPT Weight (Lbs.)
KLOC-SS-D150 1-1/2" 1-1/2" 1.74 lbs
KLOC-SS-D200 2" 2" 2.26 lbs
KLOC-SS-D300 3" 3" 3.85 lbs
Kuriyama

Kuriyama

Located in Schaumburg, Illinois, Kuriyama of America has been eminently successful in developing and marketing a complete line of thermoplastic hose and accessories. Their expansive product line consist of thermoplastic, rubber and metal hose products, along with accessories including couplings and fittings.
