NVB-1005-B by Brennan Inc. | 2-Way Ball Valve | -04 Instrumentation Fitting x -04 Instrumentation Fitting | Straight | Brass

NVB-1005-B by Brennan Inc. | 2-Way Ball Valve | -04 Instrumentation Fitting x -04 Instrumentation Fitting | Straight | Brass

$135.19 - $135.19
$135.19
$148.71
$148.71 - $148.71
$148.71

Brennan Inc.
Instrumentation Fittings: NVB - 2-Way Ball Valves
Specifications for Variant SKU: NVB-1005-B Brennan
Shape (Orientation): Straight
Ends Configuration: 1/4in Tube Compression , 1/4in Tube Compression, Some Ends Match
Material(s): Brass
Part Number Material Size Replaces Swagelok
Pt #		 Replaces Parker
Pt #

NVB-1002-B Brass 02 Instrumentation Fitting x 02 Instrumentation Fitting B-41S2 2A-B2LJ-B
NVB-1003-B Brass 02 Female Pipe x 02 Female Pipe B-42F2 2F-B2LJ-B
NVB-1005-B Brass 04 Instrumentation Fitting x 04 Instrumentation Fitting B-42S4 4A-B2LJ-B
NVB-1006-B Brass 04 Instrumentation Fitting x 04 Instrumentation Fitting B-43S4 4A-B6LJ-B
NVB-1007-B Brass 04 Female Pipe x 04 Female Pipe B-43F4 4F-B6LJ-B
NVB-1012-B Brass 06 Instrumentation Fitting x 06 Instrumentation Fitting B-43S6 6A-B6LJ-B
NVB-1013-B Brass 06 Female Pipe x 06 Female Pipe B-44F6 6F-B6LJ-B
NVB-1014-B Brass 08 Instrumentation Fitting x 08 Instrumentation Fitting B-45S8 8A-B8LJ-B
NVB-1015-B Brass 08 Female Pipe x 08 Female Pipe B-45F8 8F-B8LJ-B

NVB-1002-SS Stainless Steel 02 Instrumentation Fitting x 02 Instrumentation Fitting SS-41GS2 2A-B2LJ-SS
NVB-1003-SS Stainless Steel 02 Female Pipe x 02 Female Pipe SS-42GF2 2F-B2LJ-SS
NVB-1005-SS Stainless Steel 04 Instrumentation Fitting x 04 Instrumentation Fitting SS-42GS4 4A-B2LJ-SS
NVB-1006-SF-SS Stainless Steel 04 Instrumentation Fitting x 04 Instrumentation Fitting (Single Ferrule) - -
NVB-1006-SS Stainless Steel 04 Instrumentation Fitting x 04 Instrumentation Fitting SS-43GS4 4A-B6LJ-SS
NVB-1007-SS Stainless Steel 04 Female Pipe x 04 Female Pipe SS-43GF4 4F-B6LJ-SS
NVB-1012-SF-SS Stainless Steel 06 Instrumentation Fitting x 06 Instrumentation Fitting (Single Ferrule) - -
NVB-1012-SS Stainless Steel 06 Instrumentation Fitting x 06 Instrumentation Fitting SS-43GS6 6A-B6LJ-SS
NVB-1013-SS Stainless Steel 06 Female Pipe x 06 Female Pipe SS-44F6 6F-B6LJ-SS
NVB-1014-SF-SS Stainless Steel 08 Instrumentation Fitting x 08 Instrumentation Fitting (Single Ferrule) - -
NVB-1014-SS Stainless Steel 08 Instrumentation Fitting x 08 Instrumentation Fitting SS-45S8 8A-B8LJ-SS
NVB-1015-SF-SS Stainless Steel 08 Female Pipe x 08 Female Pipe (Single Ferrule) - -
NVB-1015-SS Stainless Steel 08 Female Pipe x 08 Female Pipe SS-45F8 8F-B8LJ-SS
NVB-1066-SS Stainless Steel 3/8" Female BSPP x 3/8" Female BSPP with Peek Ball Seal - -
Brennan

Brennan

Brennan Industries, founded in 1953, distinguishes itself with a commitment to quality in hydraulic and pneumatic fittings. With over 120,000 styles and sizes, Brennan serves a global market through extensive distribution networks. As a privately held company, Brennan's principals actively oversee operations, ensuring top-tier customer service and responsiveness. Their products meet or exceed J.I.C./S.A.E. and international standards, supported by ISO 9001:2015, AS9100D, and NADCAP certifications. Brennan's offerings include standard and custom solutions, backed by robust engineering support. With 13 distribution centers worldwide, Brennan delivers exceptional quality, service, and competitive pricing for all hydraulic and pneumatic fitting needs.
