PGS300 by Dixon Valve | Process Gauge | Lower Mount | 4-1/2" Face | 1/2" Lower Mount | 0-300 PSI Range | Plastic

Save $4.47

$125.46

$125.46 - $125.46

$125.46

$120.99

$120.99 - $120.99

$120.99

Dixon Valve
Dixon® Gauge | Process Gauge | Lower Mount

Specifically designed for process, chemical, and petroleum industries, process gauges are engineered to deliver years of accurate service while withstanding vibration, corrosive media, and corrosive atmosphere.

Quantity

Specifications for Variant SKU: PGS300 Dixon
Series:	PGS Series

Features:
Accuracy: ± 0.5% ANSI/ASME Grade 2A. Scale: single scale PSI only.
Materials:
Case: black impact resistant thermoplastic, with safety blowout back, solid front, integral back flange (dry) Ring: ethylene propylene Wetted parts: 316L stainless steel Window: poly carbonate Dial: white aluminum Pointer: black aluminum.
Specifications:
Temperature range: dry -40°F to 250°F (-40°C to 120°C)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

4-1/2" Face 1/2" Lower Mount Part Number	PSI Range	Figure Interval	Minor Gradient
PGS30	0-30 PSI	5	0.2
PGS60	0-60 PSI	10	0.5
PGS100	0-100 PSI	10	1
PGS160	0-160 PSI	20	1
PGS200	0-200 PSI	20	2
PGS300	0-300 PSI	50	2
PGS600	0-600 PSI	10	5
PGS1000	0-1000 PSI	100	10
