PP4MC4 by Parker | TrueSeal™ Threaded Fittings | 1/4" Connector x 1/4" Male NPTF Thread | 11/16" Hex | 1.14" Length | Straight | White | Polypropylene

PP4MC4 by Parker | TrueSeal™ Threaded Fittings | 1/4" Connector x 1/4" Male NPTF Thread | 11/16" Hex | 1.14" Length | Straight | White | Polypropylene

Save $0.09 Save $0.09
$1.28
$1.28 - $1.28
$1.28
$1.19
$1.19 - $1.19
$1.19

by Parker Hannifin
TrueSeal™ Fittings:MC - Male Connector
Specifications for Variant SKU: PP4MC4 Parker
Brand: TrueSeal™
Series: MC Series
Shape (Orientation): Straight
Material(s): Polypropylene
Seal Material(s): EPDM
Special Properties: Food Grade, Filtration
Product Features:
  • Acetal and Black Polypropylene (EPDM seals and metal gripping collet standard
  • White Polypropylene (EPDM seals and plastic gripping collet standard
  • Black Kynar (Fluorocarbon (FKM) seals and black kynar metal gripping collet standard
  • Gripping ring with stainless steel bite edge or with an engineered thermoplastic bite edge
  • FDA compliant, NSF/ANSI 51
  • Gray acetal and Black Polypropylene NSF/ANSI/CAN 61
Markets:
  • Food
  • Potable Water
  • Chemical
  • Filtration
Applications:
  • Air
  • Water
  • Soft Drinks
  • Beer
  • Wine
  • Dyes
  • Vacuum
Pressure Range: Acetal and Kynar:
  • 1/4", 5/16", 3/8" Vacuum to 300 PSI (20.7 bar) 1/2" Vacuum to 250 PSI (17.2 bar)
    • Polypropylene:
  • 1/4", 3/8", 1/2" Vacuum to 150 PSI (10.3 bar)
Temperature Range:
Acetal:
  • -20° to +180° F (-28.9° to +82.2° C)
    		•
    Polypropylene:
  • 0° to +225° F (-17.8° to +107.2° C)
    		•  Kynar:
  • 0° to +275° F (-17.8° to +135° C)
    		•
    Compatible Tubing:
    • Polyethylene
    • Polypropylene**
    • Nylon**
    • Vinyl+
    • Fluoropolymer**
    • Polyurethane+
    • *Kynar®

    * Registered trademark of The Arkema Group.
    ** Metal gripper required (-MG & -HBLK suffix).
    + Tube Support required.

    Gray Acetal EPDM Seal Black PPL EPDM Seal White PPL EPDM Seal Black Kynar FKM Seal Nom. Tube O.D. NPTF Thread Size Hex (C) Overall Length (L) Flow Diameter (D)
    A4MC2-MG PPB4MC2-MG PP4MC2 FB4MC2-HBLK 1/4" 1/8" 11/16" 1.28" .175"
    A4MC4-MG PPB4MC4-MG PP4MC4 FB4MC4-HBLK 1/4" 1/4" 11/16" 1.14" .175"
    A4MC6-MG PPB4MC6-MG PP4MC6 FB4MC6-HBLK 1/4" 3/8" 11/16" 1.18" .175"
    A5MC2-MG - - FB5MC2-HBLK 5/16" 1/8" 13/16" 1.46" .175"
    A5MC4-MG - - FB5MC4-HBLK 5/16" 1/4" 13/16" 1.41" .188"
    A5MC6-MG - - FB5MC6-HBLK 5/16" 3/8" 13/16" 1.27" .188"
    A6MC2-MG - PP6MC2 FB6MC2-HBLK 3/8" 1/8" 13/16" 1.46" .175"
    A6MC4-MG PPB6MC4-MG PP6MC4 FB6MC4-HBLK 3/8" 1/4" 13/16" 1.41" .250"
    A6MC6-MG PPB6MC6-MG PP6MC6 FB6MC6-HBLK 3/8" 3/8" 13/16" 1.27" .250"
    A6MC8-MG - - FB6MC8-HBLK 3/8" 1/2" 15/16" 1.45" .250"
    A8MC6-MG PPB8MC6-MG PP8MC6 FB8MC6-HBLK 1/2" 3/8" 15/16" 1.65" .360"
    A8MC8-MG PPB8MC8-MG PP8MC8 FB8MC8-HBLK 1/2" 1/2" 15/16" 1.46" .375"
