PSPJ731-2 by Parker | Pneumatic Threshold Sensor | 1/8" Male NPT Thread | 9/16" Hex | Straight | Bolt Material: Brass | Polymer

Save $37.81

$94.52

$94.52 - $94.52

$94.52

$56.71

$56.71 - $56.71

$56.71

by Parker Hannifin
Threshold Sensor Fittings:PSPJ731 Pneumatic Threshold Sensor - 10-32 Pilot

Specifications for Variant SKU: PSPJ731-2 Parker
Series:	PSPJ731 Series
Shape (Orientation):	Straight
Material(s):	Polymer, Brass
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Valved

Product Features:	Polymer body Brass screw NBR seal
Markets:	Factory/Process Automation Packaging Petrochemical Pneumatics Semi-Conductor
Applications:	Robotics Packaging Textile Machine Tools Pneumatic Systems
Pressure Range:	45 to 115 PSI (3.1 to 7.9 bar)
Temperature Range:	+5° to +140° F (-15° to +60° C)
Breaking Pressure:	8.5 PSI (0.5 bar)
Response Time:	3 MS
Model PSPE Pressure Range:	45 to 115 PSI (3.1 to 7.9 bar)
Breaking Pressure:	8.5 PSI (0.5 bar)
Current Rating:	5A/250VAC – 5W/48VDC
Compatible Tubing:	Semi-rigid nylon Polyurethane 95 Durometer Shore A Nylon Fluoropolymer


Part Number	NPT	Hex	H	L
PSPJ731-2	1/8"	9/16"	.90"	1.58"
