S40 by Dixon Valve | King Short Shank Suction Hose Coupling | Male Fitting | 4" Male NPSM x 4" Hose ID | Plated Iron

S40 by Dixon Valve | King Short Shank Suction Hose Coupling | Male Fitting | 4" Male NPSM x 4" Hose ID | Plated Iron

Save $5.48 Save $5.48
$64.89
$64.89 - $64.89
$64.89
$59.41
$59.41 - $59.41
$59.41

Dixon Valve
King Short Shank Suction Hose Coupling | Male Fitting | Male NPSM x Hose Barb

For suction or discharge of water.
Specifications for Variant SKU: S40 Dixon
Shape (Orientation): Straight
Ends Configuration: 4in Hose Barb, 4in Male NPSM
Material(s): Plated Iron
Special Properties: Short
Features:
  • Complete couplings supplied with rubber gaskets.
Male Fitting
Plated Iron
Male
Part Number		 Size
S10 1"
S15 1-1/4"
S20 1-1/2"
S25 2"
S30 2-1/2"
S36 3"
S40 4"
Female Fitting
Plated Iron Shank & Nut
Female
Part Number		 Size
S12* 1"
S17 1-1/4"
S22 1-1/2"
S27 2"
S32 2-1/2"
S38 3"
S42 4"
S62 6"
Complete Coupling
Plated Iron Shank & Nut
Complete
Part Number		 Size
S33* 1"
S48 1-1/4"
S63 1-1/2"
S78 2"
S93 2-1/2"
S111 3"
S123 4"
S183 6"

* 1" fittings have a hex nut design.

Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
