V502P-16-ACT by Parker | Rotary Actuator | 1" Size x 1" Female PTF Thread | 5.85" Length | Aluminum

V502P-16-ACT by Parker | Rotary Actuator | 1" Size x 1" Female PTF Thread | 5.85" Length | Aluminum

Save $62.14 Save $62.14
$759.57
$759.57 - $759.57
$759.57
$697.43
$697.43 - $697.43
$697.43

by Parker Hannifin
Ball Valves Rotary Actuator Series Act:Rotary Actuator, Female Pipe Ends V502P-X-ACT
Specifications for Variant SKU: V502P-16-ACT Parker
Series: V502P Series
Shape (Orientation): No Orientation
Material(s): Aluminum, Stainless Steel, Brass
Seal Material(s): PTFE
Special Properties: Extra Short, Abrasion Resistance
Product Features:
  • One Piece Aluminum Extrusion Body
  • PTFE Seals
  • Stainless Steel Shaft
  • Self Lubricated Vane Seal
  • Anodized Aluminum Extrusion Vane
Specification:
Temperature Range: -40° to +180° F (-40° to +82.2° C)
Pressure Range:
  • Up to 250 PSI (17.2 bar)
  • Vacuum service 28 inches Hg
Part Number Size A Mtg. Holes B C D E F G Hex (H) Hex (I) J (UNC) K (MPTF) L Flow Diameter Flow CV Min. Act Pressure (PSI)
V502P-4-ACT 1/4" 1/4-20 UNC 5.25" 4.47" 1.91" 2.03" 1.00" 1/4-18PTF 15/16" 15/16" 10-24 1/8"-27 1.06" .375" 4.0" 50 PSI
V502P-6-ACT 3/8" 1/4-20 UNC 5.25" 4.47" 1.91" 2.03" 1.00" 3/8-18PTF 15/16" 15/16" 10-24 1/8"-27 1.06" .375" 5.8" 50 PSI
V502P-8-ACT 1/2" 1/4-20 UNC 5.38" 4.54" 1.98" 2.20" 1.09" 1/2-14PTF* 1-1/16" 1-1/16" 10-24 1/8"-27 1.19" .500" 12.0" 50 PSI
V502P-12-ACT 3/4" 1/4-20 UNC 5.57" 4.63" 2.07" 2.42" 1.29" 3/4-14PTF** 1-5/16" 1-1/4" 10-24 1/8"-27 1.38" .685" 25.0" 75 PSI
V502P-16-ACT 1" 1/4-20 UNC 5.85" 4.76" 2.20" 2.75" 1.38" 1-11.5PTF 1-9/16" 1-1/2" 10-24 1/8"-27 1.67" .875" 35.0" 75 PSI

*PTF Special Short. **PTF Special Extra Short
