XPO-P4F by Dixon Valve | Actuated Valve Positioner | Pneumatic

XPO-P4F by Dixon Valve | Actuated Valve Positioner | Pneumatic

Save $30.83 Save $30.83
$1,152.64
$1,152.64 - $1,152.64
$1,152.64
$1,121.81
$1,121.81 - $1,121.81
$1,121.81

Dixon Valve & Coupling
Actuated Valve Positioner
Specifications for Variant SKU: XPO-P4F Dixon
Specifications:
  • Air capacity:
    • at 29 PSI (200kPa): 9.5 SCFM
    • at 87 PSI (600kPa): 28.3 SCFM
    • at 145 PSI (1MPa): 47.1 SCFM
  • Air connections: 1/4" NPT
  • Gauges: 1/8" NPT
  • Cable entry: 1/2" NPT
Part Number Positioner Type Details
XPO-E4F Electro-Pneumatic
  • Input range: 4-20mA (Ri<250ohms)
  • Supply pressure: 21.8 to 145 PSI (0.15 to 1MPa)
  • Linearity error: <1.0% f.s
  • Hysteresis: <0.6% f.s
  • Repeatability: <0.5% f.s
XPO-P4F Pneumatic
  • Input range: 3 to 15 PSI (20-100kPa)
  • Supply pressure: < 145 PSI (<1MPa)
  • Linearity error: <0.7% f.s
  • Hysteresis: <0.4% f.s
  • Repeatability: <0.3% f.s
