0661 04 11 by Parker | Slide Valve | 1/8" Female NPT Thread with .16" Male | 2.19" Length | .98" Width | .98" Height | Straight | Nickel Plated Brass

Save $1.67

$23.10

$23.10 - $23.10

$23.10

$21.43

$21.43 - $21.43

$21.43

by Parker Hannifin
Pneumatic Slide Valves:0661 Male to Female Slide Valve - NPT

Quantity

Specifications for Variant SKU: 0661 04 11 Parker
Series:	0661 Series
Shape (Orientation):	Straight
Material(s):	Nickel-Plated Brass
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Food Grade, Lightweight, Valved

Product Features:	Lightweight due to use of aluminum Nitrile Seals Immediate identification of the venting system by the color (red) Uni-directional use ensures the downstream circuit is vented Operated in the plane of the tube
Markets:	Factory/Process Automation Food Processing Packaging
Applications:	Pneumatics Conveyors Packaging Textile Plastics Engineering
Pressure Range:	Up to 230 PSI (15.8 bar)
Temperature Range:	+15° to +175° F (-9.4° to +79.4° C)


Part Number	C	Diameter Nominal (DN)	F	G	L	WT. OZ.
0661 04 11	1/8"	.16"	.55"	.98"	2.19"	2.47
0661 07 14	1/4"	.27"	.67"	1.18"	2.75"	4.59
0661 10 18	3/8"	.39"	.87"	1.38"	3.21"	7.59

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
