08E-T60 Weatherhead by Danfoss | Everflex E Series | Straight Tube Crimp Fitting | -10 Tube Size x -08 Hose Barb | Brass
08E-T60 Weatherhead by Danfoss | Everflex E Series | Straight Tube Crimp Fitting | -10 Tube Size x -08 Hose Barb | Brass
08E-T60 Weatherhead by Danfoss | Everflex E Series | Straight Tube Crimp Fitting | -10 Tube Size x -08 Hose Barb | Brass
08E-T60 Weatherhead by Danfoss | Everflex E Series | Straight Tube Crimp Fitting | -10 Tube Size x -08 Hose Barb | Brass

08E-T60 Weatherhead by Danfoss | Everflex E Series | Straight Tube Crimp Fitting | -10 Tube Size x -08 Hose Barb | Brass

$37.33 - $37.33
$37.33
$37.33 - $37.33
$37.33

Weatherhead by Danfoss
Everflex 'E' Series Crimp Fitting - Straight Tube - Straight
Specifications for Variant SKU: 08E-T60 Danfoss
Brand: Weatherhead
Series: Everflex E Series
Shape (Orientation): Straight
Ends Configuration: 5/8in Hose Barb, 1/2in Hose Barb
Material(s): Brass
Compatible with the following Series: H243 Series
Applications:
  • General purpose low and medium pressure hydraulics.
  • Use H277 where shock hazards exist.
Pressure:
  • Determined by maximum operating pressure for hose size and hose end configuration whichever is lesser.
Material:
  • Insert - Brass
  • Collar - Steel
Compatible Hose:
  • For use with H243 PTFE hose Only.
Warning:
  • For PTFE hose applications, 'E' series fittings must be used with H243 and H277 0.030" thin wall hose only
Brass
Part Number		 Hose I.D. Tube Size Thread Size A Hose Cut-Off
Factor		 Hole Dia. Sleeve
Part Number		 Nut
Part Number
08E-T58 1/2" 1/2" 3.32" 2.31" 0.39" 3/4" 1360X8 1361X8
08E-T60 1/2" 5/8" 3.45" 2.44" 0.47" 3/4" 1360X10 1361X10
12E-T60 3/4" 5/8" 3.66" 2.44" 0.47" 1" 1360X10 1361X10
12E-T62 3/4" 3/4" 4.00" 2.81" 0.61" 1" 1360X12 1361X12

Note: Drawings may differ from actual parts.
