1" H7 Couplamatic Thermoplastic Polyester Braid Hydraulic Hose (SAE 100R7) - 1" ID - 100ft

1" H7 by Couplamatic | Braid Reinforced Hydraulic Hose | SAE 100R7 | 1" ID | Thermoplastic | Polyester | 100ft

Save $64.44

$644.44

$644.44 - $644.44

$644.44

$580.00

$580.00 - $580.00

$580.00

Couplamatic Systems Inc.
Polyester Braid - H7 Thermoplastic Hydraulic Hose - (SAE 100R7)

Package Quantity: 100 FT

Quantity

Specifications for Variant SKU: 1" H7 Couplamatic \| 100 \|
Series:	H7 Series
Hose Color(s):	Black
Dash Size:	-16
Internal Diameter:	1in
Outer Diameter:	1.335in
Tubing Construction:	Nylon
Cover Construction:	Polyurethane
Applicable Specs & Approvals:	SAE 100R7
Compatible with the following Series:	3 Series \| T Series

Applications:	Medium Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R7
Cover:	Black Polyurethane, Perforated	Tube:	Nylon
Reinforcement:	Polyester Braid	Temperature:	-40F to +212F (-40C to +100C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/8" H7	1/8"	0.325"	3,000 lbs.	12,000 lbs.	0.5"	3 lbs.	250ft
3/16" H7	3/16"	0.433"	3,000 lbs.	12,000 lbs.	0.75"	4.9 lbs.	250ft
1/4" H7	1/4"	0.508"	2,750 lbs.	11,000 lbs.	1.5"	6 lbs.	250ft
5/16" H7	5/16"	0.585"	2,500 lbs.	10,000 lbs.	1.75"	7.5 lbs.	250ft
3/8" H7	3/8"	0.650"	2,250 lbs.	9,000 lbs.	2"	10 lbs.	250ft
1/2" H7	1/2"	0.815"	2,000 lbs.	8,000 lbs.	3"	15.6 lbs.	250ft
3/4" H7	3/4"	1.062"	1,250 lbs.	5,000 lbs.	6.5"	19 lbs.	100ft
1" H7	1"	1.335"	1,000 lbs.	4,000 lbs.	8"	27 lbs.	100ft

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
