2.5-B-SS by Texcel | CAM & GROOVE COUPLING LINE | Type B | 2-1/2" Female Coupler x 2-1/2" Male NPT Thread | Straight | Stainless Steel

2.5-B-SS by Texcel | CAM & GROOVE COUPLING LINE | Type B | 2-1/2" Female Coupler x 2-1/2" Male NPT Thread | Straight | Stainless Steel

Save $4.41 Save $4.41
$39.70
$39.70 - $39.70
$39.70
$35.29
$35.29 - $35.29
$35.29

Texcel
CAM & GROOVE COUPLING LINE Series | Type B Coupler
Specifications for Variant SKU: 2.5-B-SS Texcel
Series: CAM & GROOVE COUPLING LINE
Shape (Orientation): Straight
Cam Type: Type B
Ends Configuration: Cam & Groove, NPT
Material(s): Stainless Steel
Description
Aluminum constructed Cam and Groove Type B female coupler by male NPT.
Hose Diameter Part Number Lbs./Each
3/4" .75-B-ALUM Aluminum 0.26 lbs
1" 1.0-B-ALUM Aluminum 0.44 lbs
1-1/4" 1.25-B-ALUM Aluminum 0.66 lbs
1-1/2" 1.5-B-ALUM Aluminum 0.69 lbs
2" 2.0-B-ALUM Aluminum 0.85 lbs
2-1/2" 2.5-B-ALUM Aluminum 1.00 lbs
3" 3.0-B-ALUM Aluminum 1.65 lbs
4" 4.0-B-ALUM Aluminum 2.26 lbs
6" 6.0-B-ALUM Aluminum 4.37 lbs
3/4" .75-B-SS Stainless Steel N/A
1" 1.0-B-SS Stainless Steel N/A
1-1/4" 1.25-B-SS Stainless Steel N/A
1-1/2" 1.5-B-SS Stainless Steel N/A
2-1/2" 2.5-B-SS Stainless Steel N/A
3" 3.0-B-SS Stainless Steel N/A
4" 4.0-B-SS Stainless Steel N/A
5" 5.0-B-SS Stainless Steel N/A
1" 1.0-B-CS Carbon Steel N/A
1-1/2" 1.5-B-CS Carbon Steel N/A
2" 2.0-B-CS Carbon Steel N/A
3" 3.0-B-CS Carbon Steel N/A
4" 4.0-B-CS Carbon Steel N/A
3/4" .75-B-BRASS Brass 0.41 lbs
1" 1.0-B-BRASS Brass 0.64 lbs
1-1/4" 1.25-B-BRASS Brass 1.10 lbs
1-1/2" 1.5-B-BRASS Brass 1.23 lbs
2-1/2" 2.5-B-BRASS Brass 1.98 lbs
3" 3.0-B-BRASS Brass 2.88 lbs
4" 4.0-B-BRASS Brass 4.08 lbs
