3/4" CS-FLEX 4 Couplamatic Four Spiral High Pressure Import Hydraulic Hose (SAE 100R12) - 3/4" ID - 50' Bulk Length

3/4" CS-FLEX 4 by Couplamatic | Four Spiral High Pressure Import Hydraulic Hose | SAE 100R12 | 3/4" ID | 50ft Bulk Length

Save $39.13

$352.13

$352.13 - $352.13

$352.13

$313.00

$313.00 - $313.00

$313.00

Couplamatic Systems Inc.
4 High Tensile Steel Spirals - CS-FLEX 4 Four Spiral High Pressure Import Hydraulic Hose - (SAE 100R12)

Replaces RC12B

Reduced Bend Radius and Higher Working Pressures

Quantity

Specifications for Variant SKU: 3/4" CS-FLEX 4 Couplamatic \| 50 \|
Series:	CS-Flex 4 Series
Hose Color(s):	Black
Dash Size:	-12
Internal Diameter:	0.75in
Outer Diameter:	1.208in
Applicable Specs & Approvals:	SAE 100R12, Applicable MSHA Standards

Applications:	High Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R12
Cover:	Abrasion and Flame Resistant Black Cover, MSHA Approved	Reinforcement:	4 High Tensile Steel Spirals
Temperature:	-40F to +250F (-40C to +121C)	Compatible Coupling Series:	GW Series 4GC Series

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
1/2" CS-FLEX 4	1/2"	0.937"	4,060 lbs.	16,240 lbs.	3.5"	56 lbs.	Bulk
5/8" CS-FLEX 4	5/8"	1.100"	4,060 lbs.	16,240 lbs.	4"	76 lbs.	Bulk
3/4" CS-FLEX 4	3/4"	1.208"	4,060 lbs.	16,240 lbs.	4.75"	95 lbs.	Bulk
1" CS-FLEX 4	1"	1.496"	4,060 lbs.	16,240 lbs.	6"	131 lbs.	Bulk
1-1/4" CS-FLEX 4	1-1/4"	1.790"	4,060 lbs.	16,240 lbs.	8.25"	154 lbs.	Bulk
1-1/2" CS-FLEX 4	1-1/2"	2.100"	4,060 lbs.	16,240 lbs.	10"	219 lbs.	Bulk
