3/8" 025H by Couplamatic | Rubber Covered Push-on Hose | One Fiber Braid | Black | 3/8" ID | 500ft

Original price $896.30 - Original price $896.30
Original price $896.30
$923.33
$923.33 - $923.33
Current price $923.33

Couplamatic Systems Inc.
One Fiber Braid - 025H Rubber Covered Push-on Hose

Package Quantity: 500 FT

Specifications for Variant SKU: 3/8" 025H Couplamatic | 500 |
Series: 025H Series
Hose Color(s): Black
Internal Diameter: 0.375in
Outer Diameter: 0.64in
Cover Construction: Rubber
Applications: Low Pressure SAE Rating: N/A
Cover: Black Oil Resistant Rubber Reinforcement: One Fiber Braid
Temperature: -40 to +190F (-40 to +88C)
Part Number Hose ID Hose OD Working Pressure
(lbs)
Min. Burst Pressure
(lbs)
Min. Bend Radius Weight per 100ft Coil Footage
1/4" 025H 1/4" 0.500" 300 lbs. 1,200 lbs. 2.5" 9 lbs. 500ft
3/8" 025H 3/8" 0.640" 300 lbs. 1,200 lbs. 3" 11 lbs. 500ft
1/2" 025H 1/2" 0.750" 300 lbs. 1,200 lbs. 5" 13 lbs. 500ft
5/8" 025H 5/8" 0.910" 300 lbs. 1,200 lbs. 6" 19 lbs. 500ft
3/4" 025H 3/4" 1.031" 300 lbs. 1,200 lbs. 7" 21 lbs. 500ft

*Cut lengths available. 100ft minimum*
