1/4" 025H by Couplamatic | Rubber Covered Push-on Hose | One Fiber Braid | Black | 1/4" ID | 500ft

Save $68.15 Save $68.15
Original price $681.48
Original price $681.48 - Original price $681.48
Original price $681.48
Current price $613.33
$613.33 - $613.33
Current price $613.33

Couplamatic Systems Inc.
One Fiber Braid - 025H Rubber Covered Push-on Hose

Package Quantity: 500 FT

Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: 1/4" 025H Couplamatic | 500 |
Series: 025H Series
Hose Color(s): Black
Internal Diameter: 0.25in
Outer Diameter: 0.50in
MAWP: 300
Cover Construction: Rubber
Applications: Low Pressure SAE Rating: N/A
Cover: Black Oil Resistant Rubber Reinforcement: One Fiber Braid
Temperature: -40 to +190F (-40 to +88C)
Part Number Hose ID Hose OD Working Pressure
(lbs)
Min. Burst Pressure
(lbs)
Min. Bend Radius Weight per 100ft Coil Footage
1/4" 025H 1/4" 0.500" 300 lbs. 1,200 lbs. 2.5" 9 lbs. 500ft
3/8" 025H 3/8" 0.640" 300 lbs. 1,200 lbs. 3" 11 lbs. 500ft
1/2" 025H 1/2" 0.750" 300 lbs. 1,200 lbs. 5" 13 lbs. 500ft
5/8" 025H 5/8" 0.910" 300 lbs. 1,200 lbs. 6" 19 lbs. 500ft
3/4" 025H 3/4" 1.031" 300 lbs. 1,200 lbs. 7" 21 lbs. 500ft

*Cut lengths available. 100ft minimum*

Couplamatic Systems Inc

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
